Item
Parts number Parts name Area
Electrical parts list(Main board)
Remarks
Block No. 01
A
EC 7 2202-000797 C CAPACITOR
EC 8 2202-000797 C CAPACITOR
EC 9 2202-000781 C CAPACITOR
EC 10 2202-000148 C CAPACITOR
EC 11 2202-000817 C CAPACITOR
EC 12 2202-000817 C CAPACITOR
EC 20 2202-000854 C CAPACITOR
ECW 1 3711-001011 CONNECTOR
ED 1 0401-000101 DIODE 1N4148
ED 2 0401-000101 DIODE 1N4148
EIC 1 1204-001470 IC M65855FP
E
Q
1 0504-000118 TRANSISTOR KSR1003
E
Q
2 0504-000118 TRANSISTOR KSR1003
E
Q
3 0504-000118 TRANSISTOR KSR1003
ER 1 2001-000008 C RESISTOR
ER 2 2001-000508 C RESISTOR
ER 3 2001-000273 C RESISTOR
ER 4 2001-000522 C RESISTOR
ER 5 2001-000977 C RESISTOR
ER 6 2001-000290 C RESISTOR
ER 7 2001-000319 C RESISTOR
ER 8 2001-000563 C RESISTOR
ER 9 2001-000429 C RESISTOR
ER 11 2001-000273 C RESISTOR
ER 12 2001-000734 C RESISTOR
ER 13 2001-000008 C RESISTOR
ER 14 2001-000290 C RESISTOR
ER 15 2001-000290 C RESISTOR
FAN AH31-10020A FAN
FC 1 2301-000375 C CAPACITOR
FC 2 2301-000375 C CAPACITOR
FC 3 2201-000928 C CAPACITOR
FC 5 2401-001975 C CAPACITOR
FC 6 2301-000375 C CAPACITOR
FC 7 2301-000375 C CAPACITOR
FC 8 2201-000928 C CAPACITOR
FC 10 2202-000781 C CAPACITOR
FC 11 2202-000781 C CAPACITOR
FC 12 2202-000781 C CAPACITOR
FC 13 2401-000907 E CAPACITOR
FC 14 2401-001917 E CAPACITOR
FC 15 2401-001917 E CAPACITOR
FC 16 2201-000368 C CAPACITOR
FC 17 2201-000368 C CAPACITOR
FC 18 2401-001954 E CAPACITOR
FC 19 2401-001912 E CAPACITOR
FC 20 2401-001912 E CAPACITOR
FC 21 2301-000379 C CAPACITOR
FC 22 2201-000504 C CAPACITOR
FC 23 2401-001912 E CAPACITOR
FC 24 2401-001912 E CAPACITOR
FC 25 2401-001912 E CAPACITOR
FC 26 2401-001912 E CAPACITOR
FC100 2401-001895 E CAPACITOR
FC103 2201-000368 C CAPACITOR
FC104 2201-000368 C CAPACITOR
FD 1 0401-000101 DIODE 1N4148
FIC 1 1204-001621 IC LC75341
FJACK 3722-000377 JACK-RCA
F
Q
1 0504-000122 TRANSISTOR KSR1009Y
F
Q
2 0504-000122 TRANSISTOR KSR1009Y
F
Q
3 0504-001003 TRANSISTOR KSR2003
F
Q
4 0501-000407 TRANSISTOR KSD471A-Y
FR 1 2001-000613 C RESISTOR
FR 1 3602-000147 FUSE CLIP
FR 2 3601-000216 FUSE-CARTRIDGE
FR 2 2001-000241 C RESISTOR
FR 3 2001-000023 C RESISTOR
FR 4 2001-000281 C RESISTOR
FR 5 2001-000281 C RESISTOR
FR 6 2001-000281 C RESISTOR
FR 7 2001-000613 C RESISTOR
FR 8 2001-000411 C RESISTOR
FR 9 2001-000008 C RESISTOR
FR 10 2001-000008 C RESISTOR
FR 11 2001-000411 C RESISTOR
FR 12 2001-000008 C RESISTOR
FR 13 2001-000786 C RESISTOR
FR 14 2001-000008 C RESISTOR
FR 15 2001-000786 C RESISTOR
FR 16 2001-000429 C RESISTOR
FR 17 2001-000429 C RESISTOR
FR 18 2001-000221 C RESISTOR
FR 19 2001-000221 C RESISTOR
FR2CL 3602-000147 FUSE CLIP
FR2CL 3602-000147 FUSE CLIP
FW 2 3711-002809 CONNECTOR
FW 7 AH39-00157E LEAD-CONNECTOR
FZD 1 0403-000372 ZENER DIODE
JW122 2202-000854 C CAPACITOR
MC 1 2201-000565 C CAPACITOR
MC 2 2401-000303 E CAPACITOR
MC 3 2401-001975 C CAPACITOR
MCW 1 3711-000820 CONNECTOR
MD 1 0401-000101 DIODE 1N4148
MD 2 0401-000101 DIODE 1N4148
ML 1 2701-000298 INDUCTOR-AXIAL
M
Q
2 0501-000398 TRANSISTOR KSC945
M
Q
3 0501-000610 TRANSISTOR KSA928A-Y
MR 5 2001-000449 C RESISTOR
MR 6 2001-000786 C RESISTOR
MR 7 2001-000864 C RESISTOR
MR 8 2001-000786 C RESISTOR
PC 1 2401-001943 E CAPACITOR
PC 2 2401-001943 E CAPACITOR
PC 3 2201-000783 C CAPACITOR
PC 4 2201-000783 C CAPACITOR
PC 5 2201-000783 C CAPACITOR
PC 6 2201-000783 C CAPACITOR
PC 7 2401-003116 E CAPACITOR
PC 8 2401-001413 E CAPACITOR
PC 9 2401-001954 E CAPACITOR
PC 10 2401-001954 E CAPACITOR
PC 11 2401-001895 E CAPACITOR
PC 13 2401-001895 E CAPACITOR
PC 14 2401-001954 E CAPACITOR
PC 15 2401-001954 E CAPACITOR
PC 16 2401-001912 E CAPACITOR
PC 17 2401-000475 E CAPACITOR
PC 18 2401-001975 C CAPACITOR
PC 19 2401-000475 E CAPACITOR
PC 20 2401-000230 E CAPACITOR
PC 21 2401-001954 E CAPACITOR
PC 23 2201-000783 C CAPACITOR
PC 24 2201-000783 C CAPACITOR
PC 25 2401-001975 C CAPACITOR
Item
Parts number Parts name Area
Remarks
A
