JVC MX-J170V - Electrical Parts List (Front Board)

MX-J170V
3-13
Item
Parts number Parts name Area
Electrical parts list(Front board)
Remarks
Block No. 02
A
DECK 3809-001146 FLAT CABLE
GND 2 AH39-50001L LEAD-FASTEN
RE 1 AC59-60060A MODULE-REMOCON
SW 1 3404-000165 TACT SWITCH
SW 2 3404-000165 TACT SWITCH
SW 3 3404-000165 TACT SWITCH
SW 4 3404-000165 TACT SWITCH
SW 5 3404-000165 TACT SWITCH
SW 6 3404-000165 TACT SWITCH
SW 11 3404-000165 TACT SWITCH
SW 12 3404-000165 TACT SWITCH
SW 13 3404-000165 TACT SWITCH
SW 14 3404-000165 TACT SWITCH
SW 15 3404-000165 TACT SWITCH
SW 16 3404-000165 TACT SWITCH
SW 17 3404-000165 TACT SWITCH
SW 18 3404-000165 TACT SWITCH
SW 19 3404-000165 TACT SWITCH
SW 20 3404-000165 TACT SWITCH
SW 21 3404-000165 TACT SWITCH
SW 22 3404-000165 TACT SWITCH
SW 23 3404-000165 TACT SWITCH
SW 24 3404-000165 TACT SWITCH
SW 25 3404-000165 TACT SWITCH
SW 27 3404-000165 TACT SWITCH
SW 28 3404-000165 TACT SWITCH
SW 29 3404-000165 TACT SWITCH
SW 30 3404-000165 TACT SWITCH
SW 31 3404-000165 TACT SWITCH
SW 32 3404-000165 TACT SWITCH
SW 33 3404-000165 TACT SWITCH
SW 34 3404-000165 TACT SWITCH
TAPE 3809-001146 FLAT CABLE
UC 1 2401-000459 E CAPACITOR
UC 2 2401-000475 E CAPACITOR
UC 3 2201-000565 C CAPACITOR
UC 4 2201-000565 C CAPACITOR
UC 5 2201-000565 C CAPACITOR
UC 6 2401-000240 E CAPACITOR
UC 7 2201-000389 C CAPACITOR
UC 8 2201-000389 C CAPACITOR
UC 9 2201-000483 C CAPACITOR
UC 10 2201-000483 C CAPACITOR
UC 11 2401-000459 E CAPACITOR
UC 12 2401-001931 E CAPACITOR
UC 13 2401-001952 E CAPACITOR
UC 15 2202-000854 C CAPACITOR
UC 16 2201-000300 C CAPACITOR
UC 17 2202-000797 C CAPACITOR
UC 18 2202-000797 C CAPACITOR
UC 30 2401-001355 E CAPACITOR
UCW 1 3711-004420 CONNECTOR
UCW 2 3711-004424 CONNECTOR
UCW 3 3708-000454 CONNECTOR
UCW 5 AH39-00157C LEAD CONNECTOR
UCW 6 AH39-00157B LEAD CONNECTOR
UCW 7 3711-000906 CONNECTOR
UCW 8 3708-000451 CONNECTOR
UCW 9 AH39-00157A LEAD CONNECTOR
UD 20 0402-000127 DIODE 1N4002
UD 21 0402-000127 DIODE 1N4002
UD 22 0402-000127 DIODE 1N4002
UD 23 0401-000101 DIODE 1N4148
UD 24 0402-000127 DIODE 1N4002
UD 25 0401-000101 DIODE 1N4148
UD 26 0401-000101 DIODE 1N4148
UD 27 0401-000101 DIODE 1N4148
UD 28 0401-000101 DIODE 1N4148
UD 29 0401-000101 DIODE 1N4148
UD 30 0402-000127 DIODE 1N4002
UIC 1 AH11-00017B IC ROM
UIC 2 AH14-10007C IC
UIC 3 1201-000163 IC 4560
ULD 1 0601-001238 LED
UMC 1 2401-001917 E CAPACITOR
UMC 2 2401-001917 E CAPACITOR
UMC 3 2401-001917 E CAPACITOR
UMC 4 2401-001952 E CAPACITOR
UMC 5 2202-000781 C CAPACITOR
UMC 6 2401-001965 E CAPACITOR
UMC 7 2401-001917 E CAPACITOR
UMC 8 2202-000796 C CAPACITOR
UMC 9 2201-000653 C CAPACITOR
UMC10 2201-000614 C CAPACITOR
UMC21 2401-001919 E CAPACITOR
UMC22 2401-001904 E CAPACITOR
UMC23 2401-001019 E CAPACITOR
UMC24 2401-001904 E CAPACITOR
UMD 1 0401-000101 DIODE 1N4148
UMD 2 0401-000101 DIODE 1N4148
UMD 3 0401-000101 DIODE 1N4148
UMD 4 0401-000101 DIODE 1N4148
UMR 1 2001-000977 C RESISTOR
UMR 2 2001-000290 C RESISTOR
UMR 3 2001-000429 C RESISTOR
UMR 4 2001-000780 C RESISTOR
UMR 5 2001-000786 C RESISTOR
UMR 6 2001-000780 C RESISTOR
UMR 7 2001-000660 C RESISTOR
UMR 8 2001-000273 C RESISTOR
UMR 9 2001-000449 C RESISTOR
UMR10 2001-000010 C RESISTOR
UMR11 2001-000429 C RESISTOR
UMR12 2001-000290 C RESISTOR
UMR13 2001-000786 C RESISTOR
UMR14 2001-000734 C RESISTOR
UMR21 2001-000290 C RESISTOR
UMR22 2001-000319 C RESISTOR
UMR23 2001-000734 C RESISTOR
UMR24 2001-000405 C RESISTOR
UMR30 2001-000290 C RESISTOR
UMR31 2001-000786 C RESISTOR
U
Q
1 0501-000398 TRANSISTOR KSC945
U
Q
2 0501-000398 TRANSISTOR KSC945
U
Q
3 0501-000610 TRANSISTOR KSA928A-Y
U
Q
4 0504-000118 TRANSISTOR KSR1003
U
Q
5 0504-000118 TRANSISTOR KSR1003
U
Q
6 0501-000610 TRANSISTOR KSA928A-Y
U
Q
7 0501-000610 TRANSISTOR KSA928A-Y
U
Q
8 0504-000118 TRANSISTOR KSR1003
U
Q
9 0501-000398 TRANSISTOR KSC945
U
Q
10 0504-000118 TRANSISTOR KSR1003
U
Q
15 0504-000118 TRANSISTOR KSR1003
U
Q
16 0501-000398 TRANSISTOR KSC945
U
Q
16 0501-000407 TRANSISTOR KSD471A-Y
U
Q
17 0501-000398 TRANSISTOR KSC945
Item
Parts number Parts name Area
Remarks
A
