MX-J170V
3-14
Item
Parts number Parts name Area
Electrical parts list(Front board)
Remarks
Block No. 02
A
U
Q
21 0501-000398 TRANSISTOR KSC945
U
Q
22 0504-000118 TRANSISTOR KSR1003
U
Q
23 0504-001003 TRANSISTOR KSR2003
UR 1 2001-000258 C RESISTOR
UR 2 2001-000405 C RESISTOR
UR 3 2001-000241 C RESISTOR
UR 4 2001-000429 C RESISTOR
UR 5 2001-000429 C RESISTOR
UR 6 2001-000429 C RESISTOR
UR 7 2001-000734 C RESISTOR
UR 8 2001-000734 C RESISTOR
UR 9 2001-000734 C RESISTOR
UR 10 2001-000734 C RESISTOR
UR 11 2001-000734 C RESISTOR
UR 12 2001-000734 C RESISTOR
UR 13 2001-000734 C RESISTOR
UR 14 2001-000734 C RESISTOR
UR 15 2001-000734 C RESISTOR
UR 16 2001-000734 C RESISTOR
UR 17 2001-000734 C RESISTOR
UR 18 2001-000281 C RESISTOR
UR 19 2001-000429 C RESISTOR
UR 20 2001-000290 C RESISTOR
UR 21 2001-000290 C RESISTOR
UR 22 2001-000290 C RESISTOR
UR 23 2001-000290 C RESISTOR
UR 24 2001-000281 C RESISTOR
UR 25 2001-000429 C RESISTOR
UR 26 2001-000429 C RESISTOR
UR 27 2001-000429 C RESISTOR
UR 28 2001-000429 C RESISTOR
UR 29 2001-000429 C RESISTOR
UR 30 2001-000429 C RESISTOR
UR 31 2001-000591 C RESISTOR
UR 32 2001-000429 C RESISTOR
UR 33 2001-000429 C RESISTOR
UR 34 2001-000429 C RESISTOR
UR 35 2001-000429 C RESISTOR
UR 36 2001-000429 C RESISTOR
UR 37 2001-000429 C RESISTOR
UR 38 2001-000290 C RESISTOR
UR 39 2001-000290 C RESISTOR
UR 40 2001-000290 C RESISTOR
UR 41 2001-000290 C RESISTOR
UR 42 2001-000281 C RESISTOR
UR 43 2001-000281 C RESISTOR
UR 44 2001-000281 C RESISTOR
UR 45 2001-000281 C RESISTOR
UR 46 2001-000734 C RESISTOR
UR 47 2001-000449 C RESISTOR
UR 48 2001-000591 C RESISTOR
UR 49 2001-000449 C RESISTOR
UR 50 2001-000258 C RESISTOR
UR 51 2001-001178 C RESISTOR
UR 52 2001-000241 C RESISTOR
UR 53 2001-000429 C RESISTOR
UR 54 2001-000734 C RESISTOR
UR 55 2001-000591 C RESISTOR
UR 56 2001-000508 C RESISTOR
UR 57 2001-000793 C RESISTOR
UR 58 2001-000429 C RESISTOR
UR 59 2001-000241 C RESISTOR
UR 60 2001-000258 C RESISTOR
UR 61 2001-000273 C RESISTOR
UR 62 2001-000273 C RESISTOR
UR 63 2001-000273 C RESISTOR
UR 64 2001-000273 C RESISTOR
UR 65 2001-000429 C RESISTOR
UR 66 2001-000429 C RESISTOR
UR 67 2001-000449 C RESISTOR
UR 68 2001-000281 C RESISTOR
UR 69 2001-000281 C RESISTOR
UR 70 2001-000281 C RESISTOR
UR 71 2001-000429 C RESISTOR
UR 72 2001-000522 C RESISTOR
UR 73 2001-000429 C RESISTOR
UR 74 2001-000429 C RESISTOR
UR 75 2001-000429 C RESISTOR
UR 76 2001-000429 C RESISTOR
UR 77 2001-000429 C RESISTOR
UR 78 2001-000429 C RESISTOR
UR 79 2001-000429 C RESISTOR
UR 80 2001-000290 C RESISTOR
UR 81 2001-000290 C RESISTOR
UR 82 2001-000429 C RESISTOR
UR 83 2001-000273 C RESISTOR
UR 84 2001-000977 C RESISTOR
UR 85 2001-000411 C RESISTOR
UR 86 2001-000786 C RESISTOR
UR 87 2001-000290 C RESISTOR
UR 88 2001-000613 C RESISTOR
UR 89 2001-000613 C RESISTOR
UR 90 2001-000613 C RESISTOR
UR 91 2001-001178 C RESISTOR
UR 92 2001-001178 C RESISTOR
UR 93 2001-000449 C RESISTOR
UR 94 2001-000591 C RESISTOR
UR 95 2001-000290 C RESISTOR
UR 95 2001-000734 C RESISTOR
UR 96 2001-000977 C RESISTOR
UR 97 2001-000411 C RESISTOR
UR 99 2001-000522 C RESISTOR
UR100 2001-000411 C RESISTOR
UR101 2001-000977 C RESISTOR
UR102 2001-000734 C RESISTOR
UR103 2001-000786 C RESISTOR
UR201 2001-000273 C RESISTOR
UR401 2001-000290 C RESISTOR
UR402 2001-000290 C RESISTOR
UVR 1 3406-001047 ROTARY SWITCH
UVR 2 2103-000492 SEMI F.VR.
UX 1 2802-000181 CERAMIC RESONAT
UX 2 2801-001394 CRYSTAL-UNIT 32.768KHZ
UXR 1 2001-000850 C RESISTOR
UXR 2 2001-000295 C RESISTOR
UXR 3 2001-000454 C RESISTOR
VFD AH07-00016A VF-DISPLAY
