JVC MX-J170V - Electrical Parts List (CD Servo Board)

MX-J170V
3-15
Item
Parts number Parts name Area
Electrical parts list(Front board)
Remarks
Block No. 03
A
IC024 1204-001532 IC TZA1024T
IC073 1003-001192 IC TDA7073AT
IC082 1003-001162 IC-MOTOR DRIVER KA3082
IC327 0904-001353 IC 7327
IC805 AC14-12001G IC KA78L05
JR101 2007-000029 CHIP RESISTOR
JR102 2007-000029 CHIP RESISTOR
JR103 2007-000033 CHIP RESISTOR
JR104 2007-000029 CHIP RESISTOR
JR105 2007-000029 CHIP RESISTOR
JR106 2007-000029 CHIP RESISTOR
JR107 2007-000029 CHIP RESISTOR
JR109 2007-000029 CHIP RESISTOR
JR110 2007-000029 CHIP RESISTOR
JR201 2007-000029 CHIP RESISTOR
JR202 2007-000029 CHIP RESISTOR
JR203 2007-000033 CHIP RESISTOR
JR204 2007-000029 CHIP RESISTOR
JR205 2007-000029 CHIP RESISTOR
JR206 2007-000033 CHIP RESISTOR
JR207 2007-000033 CHIP RESISTOR
JR209 2007-000029 CHIP RESISTOR
JR212 2007-000033 CHIP RESISTOR
JR301 2007-000033 CHIP RESISTOR
JR302 2007-000029 CHIP RESISTOR
JR303 2007-000029 CHIP RESISTOR
JR304 2007-000029 CHIP RESISTOR
JR304 2007-000033 CHIP RESISTOR
JR305 2007-000029 CHIP RESISTOR
JR306 2007-000029 CHIP RESISTOR
JR307 2007-000033 CHIP RESISTOR
JR308 2007-000029 CHIP RESISTOR
JR309 2007-000033 CHIP RESISTOR
JR310 2007-000029 CHIP RESISTOR
JR311 2007-000033 CHIP RESISTOR
JR312 2007-000033 CHIP RESISTOR
JR313 2007-000033 CHIP RESISTOR
JR314 2007-000033 CHIP RESISTOR
JR401 2007-000033 CHIP RESISTOR
JR402 2007-000033 CHIP RESISTOR
JR403 2007-000029 CHIP RESISTOR
JR404 2007-000029 CHIP RESISTOR
JR405 2007-000033 CHIP RESISTOR
JR406 2007-000029 CHIP RESISTOR
JR407 2007-000033 CHIP RESISTOR
JW202 2007-000029 CHIP RESISTOR
MONO 3811-000122 WIRE-PVC CU
NCW 1 AH39-00061A LEAD CONNECTOR-
NCW 2 AH39-00060A LEAD CONNECTOR
NCW 3 3711-003673 CONNECTOR
NCW 5 AH39-20561P LEAD CONNECTOR
NCW 6 3708-001131 CONNECTOR
NCW 7 3711-003379 CONNECTOR
NCW 8 3708-001252 CONNECTOR
NC101 2203-000206 C CAPACITOR
NC102 2203-000595 C CAPACITOR
NC103 2203-000595 C CAPACITOR
NC104 2203-000595 C CAPACITOR
NC105 2203-000595 C CAPACITOR
NC106 2203-000787 C CAPACITOR
NC107 2203-000787 C CAPACITOR
NC108 2401-000243 E CAPACITOR
NC109 2203-000206 C CAPACITOR
NC110 2203-000206 C CAPACITOR
NC111 2203-000260 C CAPASITOR
NC114 2401-000243 E CAPACITOR
NC115 2203-000206 C CAPACITOR
NC116 2401-000243 E CAPACITOR
NC201 2203-001537 C CAPACITOR
NC202 2203-001524 C CAPASITOR
NC203 2203-000477 C CAPACITOR
NC204 2203-000609 C CAPASITOR
NC205 2203-000206 C CAPACITOR
NC206 2401-000243 E CAPACITOR
NC207 2203-000206 C CAPACITOR
NC208 2401-000243 E CAPACITOR
NC209 2401-000243 E CAPACITOR
NC210 2203-000575 C CAPACITOR
NC211 2203-000260 C CAPASITOR
NC212 2203-000260 C CAPASITOR
NC213 2203-000260 C CAPASITOR
NC214 2203-000260 C CAPASITOR
NC215 2203-000787 C CAPACITOR
NC216 2203-000787 C CAPACITOR
NC217 2203-000206 C CAPACITOR
NC218 2203-000206 C CAPACITOR
NC219 2203-000206 C CAPACITOR
NC220 2203-000260 C CAPASITOR
NC221 2202-000797 C CAPACITOR
NC301 2203-000206 C CAPACITOR
NC301 2401-000243 E CAPACITOR
NC303 2401-001511 E CAPACITOR
NC304 2401-001502 E CAPACITOR
NC305 2203-000206 C CAPACITOR
NC306 2203-000206 C CAPACITOR
NC307 2203-000802 C CAPACITOR
NC308 2203-000802 C CAPACITOR
NC309 2203-000802 C CAPACITOR
NC310 2203-000260 C CAPASITOR
NC311 2401-001511 E CAPACITOR
NC312 2401-000243 E CAPACITOR
NC313 2203-000206 C CAPACITOR
NC314 2203-000260 C CAPASITOR
NC401 2401-000243 E CAPACITOR
NC402 2401-001364 E CAPACITOR
NC403 2401-000243 E CAPACITOR
NDZ 1 0403-000341 ZENER DIODE
NDZ40 0403-000352 ZENER DIODE
NDZ40 0403-000361 ZENER DIODE
NL 2 2007-000033 CHIP RESISTOR
NL401 2001-000458 C RESISTOR
N
Q
401 0501-000616 TRANSISTOR KSC2328A-Y
NR101 2007-000267 CHIP RESISTOR
NR102 2007-000267 CHIP RESISTOR
NR104 2007-000267 CHIP RESISTOR
NR105 2007-000355 CHIP RESISTOR
NR106 2007-000355 CHIP RESISTOR
NR107 2007-000355 CHIP RESISTOR
NR108 2007-000355 CHIP RESISTOR
NR109 2007-000586 CHIP RESISTOR
NR110 2007-000586 CHIP RESISTOR
NR111 2007-000468 CHIP RESISTOR
NR112 2007-000468 CHIP RESISTOR
NR113 2007-001216 CHIP RESISTOR
NR114 2007-000941 CHIP RESISTOR
NR115 2007-000300 CHIP RESISTOR
Item
Parts number Parts name Area
Remarks
A
