MX-J170V
3-16
Item
Parts number Parts name Area
Electrical parts list(CD serve board)
Remarks
Block No. 03
A
NR116 2007-000502 CHIP RESISTOR
NR201 2007-000468 CHIP RESISTOR
NR202 2007-000586 CHIP RESISTOR
NR203 2007-000735 CHIP RESISTOR
NR204 2007-000502 CHIP RESISTOR
NR206 2007-000502 CHIP RESISTOR
NR207 2007-000981 CHIP RESISTOR
NR208 2007-000267 CHIP RESISTOR
NR209 2007-000872 CHIP RESISTOR
NR210 2001-000331 C RESISTOR
NR211 2001-000331 C RESISTOR
NR217 2001-000522 C RESISTOR
NR218 2001-000522 C RESISTOR
NR219 2001-000522 C RESISTOR
NR220 2007-000941 CHIP RESISTOR
NR221 2001-000458 C RESISTOR
NR301 2007-000468 CHIP RESISTOR
NR302 2007-000468 CHIP RESISTOR
NR303 2001-000456 C RESISTOR
NR304 2001-000456 C RESISTOR
NR305 2007-000355 CHIP RESISTOR
NR306 2007-001201 CHIP RESISTOR
NR307 2007-000355 CHIP RESISTOR
NR308 2007-001201 CHIP RESISTOR
NR309 2007-000221 CHIP RESISTOR
NR310 2007-000572 CHIP RESISTOR
NR311 2007-000572 CHIP RESISTOR
NR312 2007-000468 CHIP RESISTOR
NR313 2007-000468 CHIP RESISTOR
NR314 2007-000872 CHIP RESISTOR
NR320 2007-000241 CHIP RESISTOR
NR401 2007-001216 CHIP RESISTOR
SCW 1 3708-001438 CONNECTOR
WIRE 3811-000122 WIRE
Item
Parts number Parts name Area
Electrical parts list(Mic/Headphon board)
Remarks
Block No. 04
A
HC 1 2202-000854 C CAPACITOR
HC 2 2202-000854 C CAPACITOR
HC 3 2202-000263 C CAPACITOR
HC 4 2202-000263 C CAPACITOR
HCW 1 3711-001009 CONNECTOR
HJACK 3722-000351 PHONE JACK
HL 1 2701-000114 INDUCTOR-AXIAL
HL 2 2701-000114 INDUCTOR-AXIAL
HR 1 2001-001178 C RESISTOR
HR 2 2001-001178 C RESISTOR
MC 1 2202-000854 C CAPACITOR
MC 1 2202-000854 C CAPACITOR
MCW 1 3711-003111 CONNECTOR
MCW 1 3711-003111 CONNECTOR
MJACK 3722-000363 JACK PHONE
MJACK 3722-000363 JACK PHONE
MR 1 2001-000977 C RESISTOR
MR 1 2001-000977 C RESISTOR
MVR 1 2101-001068 V RESISTOR
MVR 1 2101-001068 V RESISTOR
