JVC MX-J170V - Electrical Parts List (Tuner Board)

MX-J170V
3-17
Item
Parts number Parts name Area
Electrical parts list(Tuner board)
Remarks
Block No. 05
A
FM PA AH40-10025N TUNER FM
HIC 1 AH14-10007G IC
MW AN AH27-00013A OSC COIL LKS75M00-0060LM
MW OS AH27-00008A OSC COIL LKS75M00-0060LM
TC 1 2203-000609 C CAPASITOR
TC 2 2203-001517 C CAPASITOR
TC 3 2203-000260 C CAPASITOR
TC 4 2401-001975 E CAPACITOR
TC 5 2203-000609 C CAPASITOR
TC 6 2203-000979 C CAPASITOR
TC 7 2203-000429 C CAPASITOR
TC 9 2401-001975 E CAPACITOR
TC 10 2203-000979 C CAPASITOR
TC 11 2401-001912 E CAPACITOR
TC 12 2401-000419 E CAPACITOR
TC 13 2203-000979 C CAPASITOR
TC 14 2201-000565 C CAPACITOR
TC 15 2203-000979 C CAPASITOR
TC 16 2401-001954 E CAPACITOR
TC 17 2401-001912 E CAPACITOR
TC 18 2401-001968 E CAPACITOR
TC 19 2401-001912 E CAPACITOR
TC 21 2401-000240 E CAPACITOR
TC 23 2401-001954 E CAPACITOR
TC 25 2401-001954 E CAPACITOR
TC 26 2401-000419 E CAPACITOR
TC 27 2401-000419 E CAPACITOR
TC 28 2203-000260 C CAPASITOR
TC 29 2203-000260 C CAPASITOR
TC 30 2401-000419 E CAPACITOR
TC 32 2203-001132 C CAPASITOR
TC 33 2203-000844 C CAPASITOR
TC 34 2401-000907 E CAPACITOR
TC 35 2203-000979 C CAPASITOR
TC 37 2401-001022 E CAPACITOR
TC 38 2401-001164 E CAPACITOR
TC 39 2201-000565 C CAPACITOR
TC 40 2202-000796 C CAPACITOR
TC 41 2203-000239 C CAPASITOR
TC 42 2202-000796 C CAPACITOR
TC 43 2401-001968 E CAPACITOR
TC 44 2203-000260 C CAPASITOR
TC 45 2203-000979 C CAPASITOR
TC 46 2401-000240 E CAPACITOR
TC 47 2401-001895 E CAPACITOR
TC 48 2202-000807 C CAPASITOR
TC 50 2203-001611 C CAPASITOR
TC 51 2203-001611 C CAPASITOR
TC 61 2203-001105 C CAPASITOR
TC 62 2203-001105 C CAPASITOR
TC 63 2203-001551 C CAPASITOR
TC 64 2203-001551 C CAPASITOR
TC 99 2203-000609 C CAPASITOR
TD 3 0401-000101 DIODE
TD 4 0401-000101 DIODE
TD 5 0401-000101 DIODE
TD 6 0401-000101 DIODE
TFL 1 2903-000119 CERAMIC FILTER SFE10.7MJA-10-A
TFL 2 2903-000105 CERAMIC FILTER
TFL 4 14529-304-610 CERAMIC FILTER AHCM2-450BL
TIC 1 AH14-10008B IC
TJ 1 3716-001156 TERMINAL BLOCK
TJ 2 3711-000814 CONNECTOR
TJW10 2007-000029 CHIP RESISTOR
TJW41 2007-000029 CHIP RESISTOR
TJW42 2007-000029 CHIP RESISTOR
TJW43 2007-000029 CHIP RESISTOR
TJW44 2007-000029 CHIP RESISTOR
TJW45 2007-000029 CHIP RESISTOR
TJW46 2007-000029 CHIP RESISTOR
TL 2 AH26-10001E IFT
TL 3 AH26-10020A TRANS DET
TLPF1 AH26-00005A IFT LKS75M00-X0002
TLPF2 AH26-00005A IFT LKS75M00-X0002
T
Q
1 0501-000398 TRANSISTOR KSC945
T
Q
2 0501-000392 TRANSISTOR KSC838-O
T
Q
3 0501-000392 TRANSISTOR KSC838-O
T
Q
4 0501-000294 TRANSISTOR
TR 1 2001-000331 C RESISTOR
TR 2 2007-000029 CHIP RESISTOR
TR 3 2001-000449 C RESISTOR
TR 4 2007-000872 CHIP RESISTOR
TR 5 2001-000281 C RESISTOR
TR 6 2007-000030 CHIP RESISTOR
TR 7 2007-000518 CHIP RESISTOR
TR 8 2007-000822 CHIP RESISTOR
TR 9 2007-000468 CHIP RESISTOR
TR 10 2007-000308 CHIP RESISTOR
TR 11 2007-000572 CHIP RESISTOR
TR 12 2007-000686 CHIP RESISTOR
TR 13 2001-000515 C RESISTOR
TR 15 2007-000586 CHIP RESISTOR
TR 16 2001-000745 C RESISTOR
TR 17 2007-000981 CHIP RESISTOR
TR 18 2001-000449 C RESISTOR
TR 19 2007-000282 CHIP RESISTOR
TR 20 2007-000409 CHIP RESISTOR
TR 21 2007-000300 CHIP RESISTOR
TR 22 2007-000300 CHIP RESISTOR
TR 23 2007-000710 CHIP RESISTOR
TR 24 2007-000290 CHIP RESISTOR
TR 25 2007-001043 CHIP RESISTOR
TR 27 2007-001071 CHIP RESISTOR
TR 28 2007-000457 CHIP RESISTOR
TR 29 2007-000686 CHIP RESISTOR
TR 30 2001-000117 C RESISTOR
TR 32 2001-000241 C RESISTOR
TR 34 2001-000241 C RESISTOR
TR 35 2007-000493 CHIP RESISTOR
TR 36 2007-000493 CHIP RESISTOR
TR 37 2007-000830 CHIP RESISTOR
TR 38 2007-001177 CHIP RESISTOR
TR 39 2001-000290 C RESISTOR
TR 40 2007-000493 CHIP RESISTOR
TR 40 2001-000522 C RESISTOR
TR 41 2001-000522 C RESISTOR
TR 42 2001-000734 C RESISTOR
TR 43 2007-000290 CHIP RESISTOR
TR 44 2001-000118 C RESISTOR
TR 44 2007-001177 CHIP RESISTOR
TR 45 2007-000282 CHIP RESISTOR
TR 46 2007-000300 CHIP RESISTOR
TR 47 2007-000282 CHIP RESISTOR
TR 48 2007-000300 CHIP RESISTOR
TR 49 2007-000282 CHIP RESISTOR
TR 50 2007-000300 CHIP RESISTOR
Item
Parts number Parts name Area
Remarks
A
