JVC MX-J170V - Electrical Parts List (VCD Board)

MX-J170V
3-18
Item
Parts number Parts name Area
Electrical parts list(Tuner board)
Remarks
Block No. 05
A
TR 51 2007-000872 CHIP RESISTOR
TR 52 2007-000468 CHIP RESISTOR
TR 53 2007-000300 CHIP RESISTOR
TR 54 2007-000300 CHIP RESISTOR
TR 55 2001-000429 C RESISTOR
TR 56 2007-000300 CHIP RESISTOR
TR 57 2001-000290 C RESISTOR
TR 58 2001-000273 C RESISTOR
TR 61 2001-000591 C RESISTOR
TR 62 2001-000591 C RESISTOR
TR101 2007-000033 CHIP RESISTOR
TR102 2007-000033 CHIP RESISTOR
TR103 2007-000033 CHIP RESISTOR
TR104 2007-000033 CHIP RESISTOR
TR105 2007-000586 CHIP RESISTOR
TSR 1 2103-000290 SEMI F.VR
TUNER 2202-000263 C CAPACITOR
TWA 1 3711-000666 CONNECTOR-HEAD
TX 1 2801-000734 CRYSTAL UNIT
TZD 1 0403-000367 ZENER DIODE
TZD 2 0403-000393 ZENER DIODE
VVC 1 0405-000137 VARACTOR DIODE
Item
Parts number Parts name Area
Electrical parts list(VCD board)
Remarks
Block No. 06
A
AAR 1 2007-000241 C RESISTOR
AC 1 2401-000243 E CAPACITOR
AC 2 2203-000206 C CAPACITOR
AC 3 2203-000206 C CAPACITOR
AC 4 2401-001502 E CAPACITOR
AI 1 1002-001124 IC
AL 1 2703-000001 INDUCTOR 10UH
ALC 1 2404-000367 TA CAPACITOR
ALC 2 2203-000323 C CAPASITOR
ALC 3 2203-000495 C CAPACITOR
ALC 4 2203-001551 C CAPASITOR
ALC 5 2404-000190 TA CAPACITOR
ALC 6 2203-001537 C CAPACITOR
ALI 1 1201-000163 IC 4560
ALR 1 2007-000872 CHIP RESISTOR
ALR 2 2007-000241 C RESISTOR
ALR 3 2007-000872 CHIP RESISTOR
ALR 4 2007-001239 C RESISTOR
ALR 5 2007-001239 C RESISTOR
ALR 6 2007-001224 C RESISTOR
ALR 7 2007-001239 C RESISTOR
ALR 8 2007-000872 CHIP RESISTOR
ALR10 2007-000282 CHIP RESISTOR
ALR11 2007-001239 C RESISTOR
AR 3 2007-000029 CHIP RESISTOR
ARC 1 2404-000367 TA CAPACITOR
ARC 2 2203-001537 C CAPACITOR
ARC 2 2203-000323 C CAPASITOR
ARC 3 2203-000495 C CAPACITOR
ARC 4 2203-001551 C CAPASITOR
ARC 5 2404-000190 TACAPACITOR
ARL 1 1201-000163 IC 4560
ARR 2 2007-000872 CHIP RESISTOR
ARR 3 2007-000872 CHIP RESISTOR
ARR 4 2007-001239 C RESISTOR
ARR 5 2007-000872 CHIP RESISTOR
ARR 6 2007-001224 C RESISTOR
ARR 7 2007-001239 C RESISTOR
ARR 8 2007-001239 C RESISTOR
ARR10 2007-000282 CHIP RESISTOR
ARR11 2007-001239 C RESISTOR
BO 2 2007-000029 CHIP RESISTOR
BR 2007-000033 CHIP RESISTOR
BR 1 2007-000290 CHIP RESISTOR
BR 2 2007-000290 CHIP RESISTOR
C 1 2203-000295 C CAPASITOR
C 2 2203-000295 C CAPASITOR
C 3 2007-000029 CHIP RESISTOR
C 4 2203-001611 C CAPASITOR
C 5 2203-001611 C CAPASITOR
C 6 2203-000260 C CAPASITOR
C 12 0801-000305 IC
CC 1 2404-000367 TA CAPACITOR
CC 2 2203-000206 C CAPACITOR
CC 3 2203-000206 C CAPACITOR
CC 4 2203-000206 C CAPACITOR
CC 5 2401-000243 E CAPACITOR
CC 6 2401-000243 E CAPACITOR
CC 7 2007-000401 CHIP RESISTOR
CC 11 2203-000749 C CAPACITOR
CC 12 2203-000749 C CAPACITOR
CC 14 2203-000206 C CAPACITOR
CI 1 1204-001141 IC CL680
