CJ 1 2007-000029 CHIP RESISTOR
CJ 2 2007-000029 CHIP RESISTOR
CJ 4 2007-000029 CHIP RESISTOR
CL 1 2007-000033 CHIP RESISTOR
C
Q
1 0502-000425 TR-POWER 2SD2395-F
CR 1 2007-000300 CHIP RESISTOR
CR 2 2007-000300 CHIP RESISTOR
CR 3 2007-000300 CHIP RESISTOR
CR 4 2007-000300 CHIP RESISTOR
CR 5 2007-000468 CHIP RESISTOR
CR 6 2007-000290 CHIP RESISTOR
CR 7 2007-000290 CHIP RESISTOR
CR 8 2007-000290 CHIP RESISTOR
CR 9 2007-000290 CHIP RESISTOR
CR 10 2007-000290 CHIP RESISTOR
CR 11 2203-001537 C CAPACITOR
CR 12 2007-000468 CHIP RESISTOR
CR 13 2007-000290 CHIP RESISTOR
CR 14 2007-000290 CHIP RESISTOR
CR 15 2007-000290 CHIP RESISTOR
CR 16 2007-000290 CHIP RESISTOR
CR 17 2007-000493 CHIP RESISTOR
CR 19 2007-000300 CHIP RESISTOR
CR 20 2007-000477 CHIP RESISTOR
CR 21 2007-000300 CHIP RESISTOR
CR 22 2007-000300 CHIP RESISTOR
CR 23 2007-000300 CHIP RESISTOR
CR 24 2007-000300 CHIP RESISTOR
CR 25 2007-000300 CHIP RESISTOR
CR 26 2007-000300 CHIP RESISTOR
CR 27 2007-000300 CHIP RESISTOR
CR 28 2007-000572 CHIP RESISTOR
CR 31 2007-000572 CHIP RESISTOR
CX 1 2801-003348 CRYSTAL 27MHZ
CZD 1 0403-000344 ZENER DIODE
DC 1 2203-000818 C CAPACITOR
DC 2 2203-000818 C CAPACITOR
GR 1 2007-000781 CHIP RESISTOR
I 1 AH14-10004R IC M74HCU04
L 1 2703-000002 INDUCTOR 100UH
LINK 6002-000398 SCREW-TAPPING 3X6
LINK 1203-000276 IC 7805
MC 1 2203-001611 C CAPASITOR
MC 2 2203-001611 C CAPASITOR
MC 3 2203-000206 C CAPACITOR
MI 1 AH09-00017B IC
MPJ 1 2007-000029 CHIP RESISTOR
MR 1 2007-000477 CHIP RESISTOR
MR 2 2007-000290 CHIP RESISTOR
MR 3 2007-000290 CHIP RESISTOR
MR 4 2007-000290 CHIP RESISTOR
MR 5 2007-000290 CHIP RESISTOR
MR 6 2007-000290 CHIP RESISTOR
MX 1 2802-000181 CERAMIC RESONAT 6MHZ
OC 8 2203-000206 C CAPACITOR
OC 12 2401-002183 E CAPACITOR
OC 13 2401-002183 E CAPACITOR
OC 15 2401-000243 E CAPACITOR
OP 1 2007-000477 CHIP RESISTOR
O
Q
2 0501-000314 TR-SMALL SIGNAL KSA812
O
Q
3 0501-000314 TR-SMALL SIGNAL KSA812
OR 1 2007-000029 CHIP RESISTOR
OR 6 2007-000572 CHIP RESISTOR
Item
Parts number Parts name Area
Remarks
A
Electrical parts list(VCD board)
Block No. 06
Item
Parts number Parts name Area
Remarks
A
OR 7 2007-000572 CHIP RESISTOR
OR 8 2007-000572 CHIP RESISTOR
OR 9 2007-000572 CHIP RESISTOR
OR 10 2203-000661 C CAPACITOR
OR 11 2007-001166 C RESISTOR
OR 12 2007-001166 C RESISTOR
PB 1 2007-000033 CHIP RESISTOR
PC 1 2401-000243 E CAPACITOR
PC 2 2203-000206 C CAPACITOR
PC 3 2203-000206 C CAPACITOR
PC 4 2203-000206 C CAPACITOR
PC 5 2203-000206 C CAPACITOR
PCON1 3711-003107 CONNECTOR
PCON1 1203-000276 IC 7805
PR 1 2007-000290 CHIP RESISTOR
R 1 2007-000267 C RESISTOR
R 2 2007-000290 CHIP RESISTOR
R 3 2007-000267 C RESISTOR
R 4 2007-000290 CHIP RESISTOR
R 5 2007-000267 C RESISTOR
R 6 2007-000290 CHIP RESISTOR
RB 2 3301-000325 CORE-FERRITE BE
RC 1 2404-000190 TA CAPACITOR
RC 2 2203-000206 C CAPACITOR
RC 3 2203-000206 C CAPACITOR
RI 1 AH11-12001A-1 IC MBH416256A-35J
RI 2 3704-000472 SOCKET-IC
RI 2 1102-001082 IC 27C020 EPROM
RR 1 2007-000290 CHIP RESISTOR
RR 1 2007-000300 CHIP RESISTOR
RR 2 2007-000300 CHIP RESISTOR
RR 2 2007-000290 CHIP RESISTOR
RR 3 2007-000290 CHIP RESISTOR
RR 5 2007-000290 CHIP RESISTOR
RR 7 2007-000290 CHIP RESISTOR
RR 8 2007-000290 CHIP RESISTOR
RR 9 2007-000290 CHIP RESISTOR
RR 10 2007-000290 CHIP RESISTOR
RR 11 2007-000290 CHIP RESISTOR
RR 12 2007-000290 CHIP RESISTOR
RR 13 2007-000290 CHIP RESISTOR
RR 14 2007-000290 CHIP RESISTOR
RR 15 2007-000290 CHIP RESISTOR
SCON3 3710-001222 CONNECTOR-SOCKE 30P
SJ 1 2007-000029 CHIP RESISTOR
SJ 2 2007-000029 CHIP RESISTOR
VB 1 2007-000029 CHIP RESISTOR
VJ 1 2007-000029 CHIP RESISTOR
VJ 2 2007-000029 CHIP RESISTOR
X 1 2801-001423 CRYSTAL 16.9344MHZ
ZR 1 2007-000931 C RESISTOR
