JVC MX-J170V - Page 76

MX-J170V
3-20
Item
Parts number Parts name Area
Electrical parts list(VCD power board)
Remarks
Block No. 07
A
FR 1 3602-000147 FUSE CLIP
FR 2 3602-000147 FUSE CLIP
VBD 1 0402-000450 DIODE-BRIDGE
VC 1 2201-000565 C CAPACITOR
VC 2 2201-000565 C CAPACITOR
VC 3 2201-000565 C CAPACITOR
VC 4 2201-000565 C CAPACITOR
VC 5 2401-001928 E CAPACITOR
VC 6 2401-001886 E CAPACITOR
VC 7 2401-000303 E CAPACITOR
VC 8 2401-001954 E CAPACITOR
VC 9 2401-001954 E CAPACITOR
VC 10 2201-000368 C CAPACITOR
VC 11 2201-000368 C CAPACITOR
VC 12 2401-001538 E CAPACITOR
VC 13 2303-000312 M CAPACITOR
VC 14 2401-001538 E CAPACITOR
VC 15 2303-000312 M CAPACITOR
VC 16 2401-001968 E CAPACITOR
VCW 1 3711-000898 CONNECTOR-HEAD
VCW 2 3711-000666 CONNECTOR-HEAD
VD 1 0401-000101 DIODE 1N4148
VD 2 0401-000101 DIODE 1N4148
VD 3 0401-000101 DIODE 1N4148
VD 4 0401-000101 DIODE 1N4148
VD 5 0401-000101 DIODE 1N4148
VD 6 0401-000101 DIODE 1N4148
VD 7 0401-000101 DIODE 1N4148
VF 1 3601-000207 FUSE CARTRIDGE
VF 2 3601-000207 FUSE CARTRIDGE
VF 2 3602-000147 FUSE CLIP
VJACK AH37-00005A RCA JACK
VJACK 3722-000379 RCA JACK
VL 1 AH27-10001F CHOKE COIL 27UH
VL 2 AH27-10001F CHOKE COIL 27UH
VPC 1 2201-000565 C CAPACITOR
VPC 2 2201-000565 C CAPACITOR
VPC 3 2201-000565 C CAPACITOR
VPC 4 2201-000565 C CAPACITOR
V
Q
1 0501-000407 TRANSISTOR KSD471A-Y
V
Q
2 0501-000294 TRANSISTOR KSA708-Y
V
Q
3 0503-001014 TRANSISTOR 2SD2495-P
V
Q
4 0504-001003 TRANSISTOR KSR2003
V
Q
5 0501-000407 TRANSISTOR KSD471A-Y
V
Q
6 0501-000407 TRANSISTOR KSD471A-Y
V
Q
7 0501-000294 TRANSISTOR KSA708-Y
V
Q
8 0502-000425 TRANSISTOR 2SD2395-F
V
Q
8 0501-000398 TRANSISTOR KSC945
VR 1 2001-000786 C RESISTOR
VR 2 2001-000786 C RESISTOR
VR 3 2001-000429 C RESISTOR
VR 4 2001-000429 C RESISTOR
VR 5 2001-000429 C RESISTOR
VR 6 2001-000429 C RESISTOR
VR 7 2001-000734 C RESISTOR
VR 8 2001-000734 C RESISTOR
VR 9 2001-000522 C RESISTOR
VR 10 2001-000008 C RESISTOR
VR 11 2001-000042 C RESISTOR
VR 12 2001-000522 C RESISTOR
VR 13 2001-000734 C RESISTOR
VR 14 2001-000522 C RESISTOR
VR 15 2001-000290 C RESISTOR
VR 16 2001-000522 C RESISTOR
VR 17 2003-000798 OMF RESISTOR
VR 18 2001-001178 C RESISTOR
VR 19 2001-000290 C RESISTOR
VR 20 2001-000786 C RESISTOR
VR 21 2001-000449 C RESISTOR
VSC 1 2201-000565 C CAPACITOR
VSC 2 2201-000565 C CAPACITOR
VSC 3 2201-000565 C CAPACITOR
VSC 4 2202-000854 C CAPACITOR
VZD 1 0403-000398 ZENER DIODE
VZD 2 0403-000399 ZENER DIODE
Item
Parts number Parts name Area
Remarks
A
