74
English
Specifications
General
Readable discs: DVD VIDEO, DVD-R (Video format), DVD-RW
(Video format), +RW (Video format), SVCD,
Video CD, Audio CD (CD-DA), MP3/WMA
format, JPEG, CD-R/RW (CD-DA, SVCD,
Video CD, MP3/WMA format, JPEG)
Video format: NTSC 525i (Interlaced scan)/525p
(Progressive scan) selectable
PAL 596i (Interlaced scan)
Other
Power requirements:
AC 110 V – 240 V , 50 Hz/60 Hz
Power consumption:
13 W (POWER ON)
1.1 W (STANDBY mode)
Mass: 2.1 kg
Dimensions (W X H X D) :
435 mm X 45 mm X 270.5 mm
Video outputs
COMPONENT (pin jacks):
Y Output: 1.0 V(p-p)/75 Ω
PB/PR Output: 0.7 V(p-p)/75 Ω
VIDEO OUT (pin jacks):
1.0 V(p-p)/75 Ω
S-VIDEO OUT (S jack):
Y Output: 1.0 V(p-p)/75 Ω
C Output: 286 mV(p-p)/75 Ω
Horizontal resolution:
500 lines or more
Audio input
MIC: 10 mVrms (8.2 kΩ)
Audio outputs
ANALOG OUT (pin jack):
2.0 Vrms (10 kΩ)
DIGITAL OUT (COAXIAL):
0.5 V(p-p) (75 Ω termination)
DIGITAL OUT (OPTICAL):
–21 dBm to –15 dBm (peak)
Audio characteristics
Frequency response
CD (sampling frequency 44.1 kHz): 2 Hz to 20 kHz
DVD (sampling frequency 48 kHz): 2 Hz to 22 kHz
(4 Hz to 20 kHz for DTS and Dolby Digital bitstream signals)
DVD (sampling frequency 96 kHz): 2 Hz to 44 kHz
Dynamic range: 16 bit: More than 98 dB
20/24 bit: More than 100 dB
Wow and flutter: Unmeasurable (less than + 0.002%)
Total harmonic distortion:
less than 0.006%
• Manufactured under license from Dolby Laboratories. “Dolby”
and the double-D symbol are trademarks of Dolby Laboratories.
• “DTS” and “DTS Digital Out” are registered trademarks of Digital
Theater Systems, Inc.
XV-NK58SL
