OVERLAY TYPE SETTING
For specifying the type of overlay during direct recording of SDI
or HDMI input signals using this unit.
Setting Values Description
OFF Disables overlay.
CHARACTER Overlays texts.
Memo :
0
Overlay is supported only for SDI and HDMI input signals.
0
If
recording is performed with the overlay type specified, it will
be recorded together with the video. You cannot hide the
overlaid information from the recorded movie.
0
OVERLAY SIZE SETTING
For specifying the size of the overlay object.
Setting Values Description
SMALL Sets the overlay object size to small.
BIG Sets the overlay object size to large.
0
OVERLAY TRANSMITTANCE SET
For specifying the transparency of the overlay object.
Setting Values Description
0% Overlay object is opaque.
50% Overlay object is 50% transparent.
75% Overlay object is 75% transparent.
0
OVERLAY DISP. POSITION SET
For specifying the position for displaying the overlay object.
Setting Values Description
LOWER LEFT Displays the overlay object at the bottom
left.
LOWER RIGHT Displays the overlay object at the bottom
right.
UPPER LEFT Displays the overlay object at the top left.
UPPER RIGHT Displays the overlay object at the top right.
CENTER Displays the overlay object at the center.
Memo :
0
Overlay
information can be displayed together with the “TIME
CODE” or “DATE & TIME” display under “TIME CODE INPUT
SETTING”.
0
OVERLAY INPUT SCREEN
Selectable when “OFF” is not selected for “OVERLAY TYPE
SETTING”. (Not selectable when “OFF” is selected.)
A text input screen appears when “CHARACTER” is selected
for “OVERLAY TYPE SETTING”.
Alphabets and ASCII codes can be used.
The maximum number of characters that can be entered is
25.
0
PASSWORD INITIALIZATION
Resets the preset password and restores to the unspecified
state.
Memo :
0
Entry of the current password is needed in order to perform
password reset.
0
This item appears grayed out and cannot be selected if a
password has not been set.
94
