7.2.4 Change the Fuse
The Calibrator has a product fuse that protects from overcurrent.
WARNING!
To prevent possible electrical shock, fire, or personal injury, use only specified replacement
parts.
To replace the fuses (see Figure 24 below):
1. Disconnect the mains-power cord from the power-entry module.
2. Open the power entry module and remove the fuse holder.
3. Replace the fuse with exact replacements as indicated in the specifications in Chapter 2.
Figure 24: Changing the Product Fuse
V
5
1
1
115V
115V
V51
1
V
032
PRSR
1
2
3
4
Product Fuse
