KEB COMBIVERT F5 MULTI User Manual

6
6
115
KEB COMBIVERT F5-M / S
Name: Basis
12.05.04
Section PageDate
© KEB Antriebstechnik, 2002
All Rights reserved
Chapter
Functional DesriptionOperating and Unit Data
Adr.
min max
default
022Ah
ru.42 Modulation grade
1
%
-
1100
The modulation grade shows the output voltage in percent. 100 % correspond to the input voltage (no-load). At a value
of > 100†% the inverter works with overmodulation.
Adr.
min max
default
Adr.
min max
default
Adr.
min max
default
Adr.
min max
default
0227h
ru.39 OL counter display
1
%
-
1000
To prevent ÑE.OLì errors caused by too high loads (load reduction), the internal counter content of the OL-counter can be
made visible herewith. At 100 % the inverter switches off with the error ÑE.OLì. The error can be reset only after a cooling
time (blinking display ÑE.nOLì).
0226h
ru.38 Power module temperature
1
∞C
-
1500
ru.38 shows the actual power module temperature of the inverter.
0228h
ru.40 Power on counter
1
h
-
655350
The operating hours meter 1 displays the time the inverter was switched on. The indicated value includes all operating
phases. On attaining the maximum value (approx. 7.5 years) the display remains on the maximum value.
0229h
ru.41 Modulation on counter
1
h
-
655350
The operating hours meter 2 displays the time the inverter was active (motor controlled). On attaining the maximum
value (approx. 7.5 years) the display remains on the maximum value.
Adr.
min max
default
022Bh
ru.43 Timer 1 display
0,01
-
-
655,350
The count of the free-programmable timer 1 is indicated. The display is done either in seconds or hours (see LE.21). The
counter can a adjusted to any chosen value by keyboard or bus. The programming of the counter is done with the
parameters LE.17...LE.21 (also see Chapt. 6.9.4 ÑTimerì).
