Page #148 background image
6 3
KEB COMBIVERT F5
14
Name: Basis
28.01.03
Chapter Section Page Date
© KEB Antriebstechnik, 2002
All rights reserved
Functional Description Digital In- and Outputs
33 AN3 on output of characteristic amplifier > level; without sign evaluation
34 AN1 on output of characteristic amplifier > level; with sign evaluation
35 AN2 on output of characteristic amplifier > level; with sign evaluation
36 AN3 on output of characteristic amplifier > level; with sign evaluation
37 Timer 1 > level
38 Timer 2 > level
39 Angle difference > level (only F5-M/S)
40 Hardware current limit active
41 Modulation on-signal
42 Output of analog signal ANOUT3 as PWM-signal. The period is adjusted with An.46.
43 Output of analog signal ANOUT4 as PWM-signal. The period is adjusted with An.52.
44 Inverter state (ru.0) = Level
45 Power module temperatur (ru.38) > Level
46 Motor temperatur (ru.46) > Level
47 Ramp output value (ru.2) > Level
48 Apparent current (ru.15) > Level
49 Clockwise rotation (not at noP, LS, abnormal stopping, error)
50 Counter clockwise (not at noP, LS, abnormal stopping, error)
51 Warning E.OL2
52 Current control at the limit (only F5-M/S)
53 Speed control at the limit
54 Target window reached (Posi module at F5-M/S)
55 Current position > Level (Posi module at F5-M/S)
56 Positioning active (Posi module at F5-M/S)
57 Position inaccessible (Posi module at F5-M/S)
58 Profile processing active (Posi module at F5-M/S)
59 AND-operation of the selected inputs. The condition is active, if all selected inputs are active. The selection is
done with the switching levels (LE.0...7) according to following table:
Input ST RST F R I1 I2 I3 I4 IA IB IC ID
Value 1 2 4 8 16 32 64 128 256 512 1024 2048
The sum of the inputs to be queried is entered in the switching levels.
Example:
If the inputs I3 and I4 are active, the condition do.4 shall be set.
Adjust switching condition 4 (do.4) to „59“. Adjust switching level 4 (LE.4) to „192“ („64“ for I3 + „128“ for I4).
60 OR-operation of the selected inputs. The condition is active, if at least one of the selected inputs is active.
Adjustment as at value „59“.
61 NAND-operation of the selected inputs. The condition is active, if at least one of the selected inputs is inactive.
Adjustment as at value „59“.
62 NOR-operation of the selected inputs. The condition is active, if all of the selected inputs are inactive.
Adjustment as at value „59
63 Absolute value ANOUT1 > Level
64 Absolute value ANOUT2 > Level
65 ANOUT1 > Level
66 ANOUT2 > Level
67 Active relative position > Level. The output is set, if the distance covered after the starting position is larger than
the adjusted level. That means, the function works relative to the starting position. If the positioning is
completed, the output is reset (Posi module at F5-M/S).
68 Active position to the target > Level. The output is set, if the distance to be covered to the target is larger than
the adjusted level. If the positioning is completed, the output is reset (Posi module at F5-M/S).
69 Absolute control difference of the external PI controller > Level
70 Driver voltage activ (driver relay)
