Functional DescriptionDigital In- and Outputs
The hysteresis, in reference to the adjusted values, defines the parameters
LE. 8...LE.15. Hysteresis 0 (LE.8) applies for comparison level 0; LE.9 for comparison
level 1 ... and so forth.
Default:
Frequency: 0,5 Hz
Voltage: 1 V
Analog values: 0,5 %
Current: 0,5 A
Temperature: 1 °C
LE.16 defines the hysteresis for the status constant-run and tripping frequencies for
the DC-brake.
Hysteresis 0...7
LE. 8...LE.15
Frequency hysteresis LE.16
Response to warning signals
Pn.8, Pn.10, Pn.12, Pn.14,
Pn.16
These parameters determine the behaviour of the inverter in case of warning signals.
To learn more about the adjustment possibilities as well as the performance of the
appropriate drive please refer to Chapter 6.7 „Protective functions“.
Level 0...7
LE.0...LE.7
These parameters defines the level of the switching conditions. Level 0 (LE.0) applies
for switching condition 0; LE.1 for switching condition 1 ... and so forth.
Setting range: -30000,00...30000,00
Step: 0,01
Default: see parameter table
At pretending in increments one increment is 0,01.
71 Drive runs synchronously; is set, if after the activation of the synchronous run the drive is synchronized (F5-M/
S).
72 Actual position index = Level (Posi modul at F5-M/S)
73 Absolute active power > Level
74 Active power > Level
75 Absolute (actuel position – scan position) > Level (Posi modul at F5-M/S)
