Page #87 background imageLoading...
Page #87 background image
Parameter
5
111
KEB COMBIVERT F5-G / C / B
Name: Basis
10.05.04
Section PageDate
© KEB Antriebstechnik, 2002
All Rights reserved
Chapter
Parameter Adr. Control Properties min. max. Step default [?] see on Page
5
op53 motorpoti min. value 0335 B C g G M S A ---- -100,00 100,00 0,01 0,00 % 6.9.8
op54 motorpoti max. value 03 36 B C g G M S A ---- -100,00 100,00 0,01 100,00 % 6.9.8
op55 motorpoti reset value 0337 B C g G M S A ---- -100,00 100,00 0,01 0,00 % 6.9.7
op56 Eing.wahl MPoti erhˆhen 03 38 B C g G M S A - - E - 0 4095 1 0 - 6.3.8, 6.9.8
op57 mot.poti dec. input sel. 03 39 B C g G M S A - - E - 0 4095 1 0 - 6.9.8, 6.3.8
op58 mot.poti reset inp. sel. 03 3A B C g G M S A - - E - 0 4095 1 0 - 6.9.8, 6.3.8
op59 motorpoti inc/dec time 03 3B B C g G M S A ---- 0,00 50000,00 0,01 66,00 s 6.9.8
op60 dir. forward input sel. 033C B C g G M S A - - E - 0 4095 1 4 - 6.3.8, 6.4.7
op61 dir. reverse input sel. 03 3D B C g G M S A - - E - 0 4095 1 8 - 6.3.8, 6.4.7
op62 acc/dec time factor 03 3E B C g G M S A - - E - 0 4 1 0 - 6.4.13
pn 0 auto retry UP 0400 B C g G M S A ---- 0 1 1 1 - 6.7.7
pn 1 auto retry OP 04 01 B C g G M S A ---- 0 1 1 0 - 6.7.7
pn 2 auto retry OC 04 02 B C g G M S A ---- 0 1 1 0 - 6.7.7
pn 3 E. EF stopping mode 04 03 B C g G M S A ---- 0 6 1 0 - 6.7.10
pn 4 ext. fault input select 0404 B C g G M S A - - E - 0 4095 1 64 - 6.7.9, 6.3.8
pn 5 E.buS stopping mode 04 05 B C g G M S A ---- 0 6 1 6 - 6.7.10, 11.2.3
pn 6 watchdog time 04 06 B C g G M S A - - E - 0,00:off 10,00 0,01 0,00:off s 6.7.10, 11.2.3
pn 8 warning OL stop. mode 04 08 B C g G M S A ---- 0 6 1 6 - 6.7.11, 6.3.15
pn 9 OL warning level 04 09 B C g G M S A ---- 0 100 1 80 % 6.7.10
pn10 warning OH stop. mode 04 0A B C g G M S A ---- 0 6 1 6 - 6.7.11, 6.3.15
pn11 OH warning level 040B B C g G M S A ---- 0 90 1 70 C 6.7.11
pn12 warning dOH stop. mode 04 0C B C g G - - - ---- 0 7 1 7 - 6.7.11, 6.3.15, 6.7.18
pn13 E.dOH delay time 04 0D B C g G - - - ---- 0 120 1 10 s 6.7.11, 6.7.18
pn14 warning OH2 stop. mode 04 0E B C g G M S A ---- 0 6 1 6 - 6.7.12, 6.7.17, 6.3.15
pn16 warning OHI stop. mode 04 10 B C g G M S A ---- 0 7 1 7 - 6.7.12, 6.3.16
pn17 E.OHI delay time 04 11 B C g G M S A ---- 0 120 1 0 s 6.7.12
pn18 E.Set stopping mode 04 12 B C g G M S A ---- 0 6 1 0 - 6.7.12
pn19 stall mode 04 13 - C - G M - - - P E - 0 255 1 0 - 6.7.5
pn19 stall mode 04 13 B - g - - - A - P E - 0 127 1 0 - 6.7.5
pn20 stall level 04 14 B C g G M - A - P - - 0 200 1 200:off % 6.7.6
pn21 stall acc/dec time 04 15 B C g G M - A - P - - 0 300,00 0,01 2,00 s 6.7.6
pn22 LAD stop function 0416 B C g G M S A - P E - 0 7 1 1 / 0 - 6.7.3
pn23 LAD stop input selection 04 17 B C g G M S A - - E - 0 4095 1 0 - 6.7.3, 6.3.8
pn24 LAD load level 04 18 B C g G M S A - P - - 0 200 1 140 % 6.7.3
pn25 LD voltage 04 19 B C g G M S A - P - - 200 800 1 375 / 720 V 6.7.3
pn26 speed search condition 04 1A B C g G M - - - P E - 0 15 1 8 - 6.7.7
pn27 speed search mode 04 1B B C g G M - - - - E - 0 127 1 0/88 - 6.7.7
pn28 DC braking mode 04 1C B C g G M - - - P E - 0 9 1 7 - 6.9.4
pn29 DC brake input selection 04 1D B C g G M - - - - E - 0 4095 1 128 - 6.9.4, 6.3.8
pn30 DC braking time 04 1E B C g G M - - - P - - 0,00 100,00 0,01 10,00 s 6.9.3
pn31 DC braking max. voltage 04 1F B C g G M - - - P - - 0,0 25,5 0,1 25,5 % 6.9.3
pn32 DC braking start freq. 0420 B C g G - - - - P - V 0 400 0,0125 4 Hz 6.9.3
pn34 brake control mode 04 22 B C g G M S A - P E - 0 4 1 0 - 6.9.16
pn35 premagnetizing time 04 23 B C g G M S A - P - - 0,00 100,00 0,01 0,25 s 6.9.15
pn36 brake release time 04 24 B C g G M S A - P - - 0,00 100,00 0,01 0,25 s 6.9.15
pn37 Bremsenstrg. Startwert 04 25 B C g G - - - - P - V -20 20 0,0125 0 Hz 6.9.17
pn39 brake delay time 04 27 B C g G M S A - P - - 0,00 100,00 0,01 0,25 s 6.9.15
pn40 brake closing time 04 28 B C g G M S A - P - - 0,00 100,00 0,01 0,25 s 6.9.15
pn41 brake ctrl. stop ref. 04 29 B C g G - - - - P - V -20 20 0,0125 0 Hz 6.9.17
pn41 brake ctrl. stop ref. 04 29 - - - - M S A - P - V -600 600 0,125 0 rpm 6.9.17
pn43 min. load brake ctrl. 042B B C g G M S A - P - - 0 100 1 0 % 6.9.16
pn44 power off mode 04 2C B C g G M S A - - E - 0 511 1 0 - 6.9.19, 6.9.20, 6.9.23
pn45 power off start voltage 04 2D B C g G M S A ---- 200 800 1290 / 500 V 6.9.20, 6.9.21
pn46 power off auto st. level 04 2E B C g G M S A ---- 50 90 1 80 % 6.9.20, 6.9.21
pn47 power off brake torque 04 2F B C g G - - - ---- 0,0 100,0 0,1 0,0 % 6.9.21
pn48 power off restart level 04 30 B C g G - - - - - - V 0 400 0,0125 0 Hz 6.9.22
pn50 power off ref. DC volt. 04 32 B C g G - - - ---- 200 800 1290 / 500 V 6.9.21
pn51 power off KP DC volt. 0433 B C g G M - - ---- 0 32767 1 128 - 6.9.22
pn52 power off restart delay 04 34 B C g G M S A ---- 0,00 100,00 0,01 0,00 s 6.9.23
pn53 power off KP act.curr. 04 35 B C g G - - - ---- 0 32767 1 50 - 6.9.22
pn54 power off KI act.curr. 04 36 B C g G - - - ---- 0 32767 1 50 - 6.9.22
pn55 power off KD act.curr. 04 37 B C g G - - - ---- 0 32767 1 0 - 6.9.22
pn56 power off jump factor 0438 B C g G - - - ---- 0 800 1 100 % 6.9.20
pn57 power off KI DC volt. 04 39 - C - G M - - ---- 0 32767 1 5 - 6.9.22
pn58 quick stop mode 04 3A B C g G - - A - - E - 0 3 1 0 - 6.7.13
pn59 quick stop level 043B B C g G - - - ---- 0 200 1 200 % 6.7.13
pn60 quick stop acc/dec time 04 3C B C g G M S A ---- 0 300,00 0,01 2,00 s 6.7.13
pn62 dOH warning level 04 3E - - - G M S A ---- 0 200 1 100 C 6.7.11
pn63 positioning delay 04 3F B C g G - - A - P - - -0,02 327,67 0,01 -0,01 s 6.9.31
pn64 set GTR7 input selection 04 40 - C - G M S A - - E - 0 4095 1 0 - 6.7.19, 6.3.8
pn65 special functions 04 41 - C - G M S A ---- 0 7 1 0 - 6.7.20, 6.7.19, 6.7.9
pn69 GTR7 voltage 04 19 - C g G M S A 300 1000 1 380;740 V
ru 0 inverter state 02 00 B C g G M S A R - - - 0 255 1 0 - 6.1.6
ru 1 set value display 02 01 B C g G - - - R - - V -400 400 0,0125 0 Hz 6.1.6, 6.9.3
ru 2 ramp output display 02 02 B C g G - - - R - - V -400 400 0,0125 0 Hz 6.1.6
ru 3 actual frequency display 02 03 B C g G M S A R - - V -400 400 0,0125 0 Hz 6.1.6
ru 4 encoder 1 frequency 02 04 - - - G - - A R - - V -400 400 0,0125 0 Hz
