Parameter
5 1
KEB COMBIVERT F5-G / C / B
12
Name: Basis
10.05.04
Chapter Section Page Date
© KEB Antriebstechnik, 2002
All Rights reserved
Parameter Adr. Control Properties min. max. Step default [?] see on Page
ru 5 encoder 2 frequency 02 05 - - - G - - A R - - V -400 400 0,0125 0 Hz
ru 6 calculated act. freq. 02 06 - - - G - - A R - - V -400 400 0,0125 0 Hz
ru 7 actual value display 02 07 - - - G - - - R - - V -400 400 0,0125 0 Hz 6.1.7
ru 9 encoder 1 speed 0209 - - - G - - - R - - V -32000 32000 1 0 rpm 6.1.7
ru 10 encoder 2 speed 02 0A - - - G - - - R - - V -32000 32000 1 0 rpm 6.1.7
ru 13 actual utilization 020D B C g G M S A R - - - 0 65535 1 0 % 6.11.6, 6.1.8
ru 14 peak utilization 020E B C g G M S A - - - - 0 65535 1 0 % 6.1.8
ru 15 apparent current 02 0F B C g G M S A R - - - 0 6553,5 0,1 0 A 6.1.8
ru 16 peak apparent current 02 10 B C g G M S A - - - - 0 6553,5 0,1 0 A 6.1.8
ru 17 active current 02 11 B C g G M S A R - - - -3276,7 3276,7 0,1 0 A 6.12.6, 6.1.9
ru 18 actual DC voltage 02 12 B C g G M S A R - - - 0 1000 1 0 V 6.12.6, 6.1.9
ru 19 peak DC voltage 02 13 B C g G M S A - - - - 0 1000 1 0 V 6.1.9
ru 20 output voltage 0214 B C g G M S A R - - - 0 778 1 0 V 6.1.9
ru 21 input terminal state 02 15 B C g G M S A R - - - 0 4095 1 0 - 6.1.10, 6.3.5
ru 22 internal input state 02 16 B C g G M S A R - - - 0 4095 1 0 - 6.1.10, 6.3.8
ru 23 output condition state 0217 B C g G M S A R - - - 0 255 1 0 - 6.1.11
ru 24 state of output flags 02 18 B C g G M S A R - - - 0 255 1 0 - 6.1.11
ru 25 output terminal state 02 19 B C g G M S A R - - - 0 255 1 0 - 6.1.12, 6.3.18
ru 26 active parameter set 02 1A B C g G M S A R - - - 0 7 1 0 - 6.1.12
ru 27 AN1 pre amplifier disp. 02 1B B C g G M S A R - - - -100,0 100,0 0,1 0 % 6.1.12, 6.2.3, 6.4.4
ru 28 AN1 post amplifier disp. 02 1C B C g G M S A R - - - -400,0 400,0 0,1 0 % 6.1.12, 6.2.3, 6.4.4
ru 29 AN2 pre amplifier disp. 02 1D - C g G M S - R - - - -100,0 100,0 0,1 0 % 6.1.13, 6.2.3, 6.4.4
ru 30 AN2 post amplifier disp. 02 1E - C g G M S - R - - - -400,0 400,0 0,1 0 % 6.1.13, 6.2.3, 6.4.4
ru 31 AN3 pre amplifier disp. 02 1F - - - G M S - R - - - -100,0 100,0 0,1 0 % 6.1.13, 6.2.3, 6.4.4
ru 32 AN3 post amplifier disp. 02 20 - - - G M S - R - - - -400,0 400,0 0,1 0 % 6.1.13, 6.2.3, 6.4.4
ru 33 ANOUT1 pre ampl. disp. 02 21 B C g G M S A R - - - -400,0 400,0 0,1 0 % 6.1.14, 6.2.12
ru 34 ANOUT1 post ampl. disp. 0222 B C g G M S A R - - - -115,0 115,0 0,1 0 % 6.1.14, 6.2.12
ru 35 ANOUT2 pre ampl. disp. 02 23 - C g G M S - R - - - -400,0 400,0 0,1 0 % 6.1.14, 6.2.12
ru 36 ANOUT2 post ampl. disp. 0224 - C g G M S - R - - - -115,0 115,0 0,1 0 % 6.1.14, 6.2.12
ru 37 motorpoti actual value 02 25 B C g G M S A R - - - -100,00 100,00 0,01 0 % 6.1.14, 6.9.8
ru 38 power module temperature 02 26 B C g G M S A R - - - 0 150 1 0 C 6.1.15
ru 39 OL counter display 02 27 B C g G M S A R - - - 0 100 1 0 % 6.1.15
ru 40 power on counter 02 28 B C g G M S A R - - - 0 65535 1 0 h 6.1.15
ru 41 modulation on counter 0229 B C g G M S A R - - - 0 65535 1 0 h 6.1.15
ru 42 modulation grade 02 2A B C g G M S A R - - - 0 110 1 0 % 6.1.15
ru 43 timer 1 display 022B B C g G M S A - - - - 0 655,35 0,01 0 - 6.1.15, 6.9.12
ru 44 timer 2 display 022C B C g G M S A - - - - 0 655,35 0,01 0 - 6.1.16, 6.9.12
ru 45 act. carrier frequency 02 2D B C g G M S A R - - - 0 4 1 0 - 6.1.16
ru 46 motor temperature 02 2E B C g G M S - R - - - 0 255 1 0 C 6.1.16
ru 52 ext. PID out disp. 02 34 B C g G M S A R - - - -100,0 100,0 0,1 0 % 6.1.17, 6.4.4
ru 53 AUX display 02 35 B C g G M S A R - - - -400,0 400,0 0,1 0 % 6.1.17, 6.12.6
ru 68 rated DC voltage 02 44 B C - G M S A R - - - 0 1000 1 0 V 6.1.17
ru 69 distance ref.-zeropoint 02 45 B - - G M S A R - - - -2^31 2^31 ñ 1 0 1 inc. 6.1.17
ru 71 teach/scan position 02 47 B - - G M S A R - - - -2^31 2^31 ñ 1 0 1 inc. 6.1.17
ru 73 set torque in percent 02 49 B - - G M S A R - - - -100,0 100,0 0,1 0 % 6.1.17
ru 74 act torque in percent 02 4A B - - G M S A R - - - -100,0 100,0 0,1 0 % 6.1.17
ru 78 act. val. display in percent 02 4E B - - G M S A R - - - -100,0 100,0 0,1 0 % 6.1.17
ru 79 abs. speed value 02 4F B - - G M S A R - - - n*-4000 n*4000 n*0,125 0 rpm 6.1.17
ru 80 digital output state 0250 B C - G M S A R - - - 0 255 1 0 - 6.1.18
ru 81 active power 02 51 B C - G M S A R - - - -400 400 0,00 0,00 kW 6.1.18
sy 2 inverter identifier 00 02 B C g G M S A - - - - identifier identifier 1 identifier hex 6.1.23
sy 3 power unit code 00 03 B C g G M S A - - E - 1 255 1 LTK - 6.1.23
sy 6 inverter address 00 06 B C g G M S A - - E - 0 239 1 1 - 6.1.23, 11.2.3
sy 7 baud rate ext. bus 00 07 B C g G M S A - - E - 0 6 1 5 - 6.1.23, 11.2.3
sy 9 HSP5 watchdog time 00 09 B C g G M S A - - E - 0,00:off 10,00 0,01 0,00:off s 6.1.24, 11.2.3
sy11 baud rate int. bus 00 0B B C g G M S A - - E - 3 11 1 5 - 6.1.24, 11.2.3
sy32 scope timer 0020 B C g G M S A R - - - 0 65535 1 0 - 6.1.24
sy41 control word (high) 00 29 - C - G M S A - - E - 0 65535 1 0 hex 6.1.24, 11.2.4
sy42 status word (high) 00 2A - C - G M S A R - - - 0 65535 1 0 hex 6.1.25, 11.2.5
sy43 control word (long) 00 2B - C - G M S A R - - - -2^31 2^31 - 1 1 0 hex 6.1.25, 11.2.5
sy50 control word (low) 0032 B C g G M S A - - E - 0 65535 1 0 hex 6.1.25, 6.4.8, 11.2.4
sy51 status word (low) 00 33 B C g G M S A R - - - 0 65535 1 0 hex 6.1.25, 11.2.4
sy52 set speed value 0034 B C g G M S A - - - - -16000 16000 1 0 rpm 6.1.26, 11.2.4
sy53 actual speed value 00 35 B C g G M S A R - - - -16000 16000 1 0 rpm 6.1.25, 11.2.4
sy56 start display address 0038 B C g G - - A - - E - 0 7FFFH 1 0203H hex 6.1.25
ud 1 password 08 01 B C g G M S A - - - - 0 9999 1 - - 4.2.3, 4.4.3, 6.13.3
ud 2 maximum frequency mode 08 02 B C g -------- 0 2 1 0 - 6.5.3
ud 2 control type 0802 - - - G M S A - - E - 0 10 1 0 - 6.5.3
ud 5 auto store 0805 B C g -------- 0 1 1 1 - 11.2.3
ud 9 drive-mode-control 0809 B C g G M S A - - - - 0 11 1 0 - 4.4.4
ud15 cp selector 08 0F B C g G M S A - - E - 1 36 1 1 - 6.13.4
ud16 cp address 08 10 B C g G M S A - - E - -1 32767 1 Tabelle hex 6.13.4
ud17 cp set norm 08 11 B C g G M S A - - E - 1 32767 1 1 - 6.13.4
ud18 divisor display norm 08 12 B C g G M S A - P E - -32767 32767 1 1 - 6.13.6
ud19 multiplier display norm 0813 B C g G M S A - P E - -32767 32767 1 1 - 6.13.6
ud20 offset display norm 08 14 B C g G M S A - P E - -32767 32767 1 0 - 6.13.6
ud21 ctrl. display norm 08 15 B C g G M S A - P E - 0 1791 1 0 - 6.13.6
