KEB COMBIVERT F5 MULTI User Manual

6
1
KEB COMBIVERT F5-M / S8
Name: Basis
12.05.04
Chapter Section Page Date
© KEB Antriebstechnik, 2002
All Rights reserved
Functional Desription Operating and Unit Data
Adr.
min max
default
0210h
ru.16 Peak apparent current
0,1
A
-
6553,50
ru.16 allows the detection of short-time peak currents during an operating cycle. For that the highest detected value of
ru.15 is stored in ru.16. The peak value memory is cleared by pressing the keys UP, DOWN or ENTER or by bus by
writing any chosen value to the address of ru.16. The disconnection of the inverter also results in a clearing of the
memory.
Adr.
min max
default
Adr.
min max
default
020Dh
ru.13 Actual utilization
1
%
-
655350
Display of the current utilization referred to the rated current of the inverter. Only positive values are indicated, thus it is
not possible to differentiate between a motoric or generatoric operation.
020Eh
ru.14 Peak utilization
1
%
-
655350
ru.14 allows the detection of short-time peak utilizations during an operating cycle. For that the highest detected value
of ru.13 is stored in ru.14. The peak value memory is cleared by pressing the keys UP, DOWN or ENTER or by bus by
writing any chosen value to the address of ru.14. The disconnection of the inverter also results in a clearing of the
memory.
Adr.
min max
default
020Fh
ru.15 Apparent current
0,1
A
-
6553,50
Display of actual apparent curent.
