KEB COMBIVERT F5 MULTI User Manual

6
6
19
KEB COMBIVERT F5-M / S
Name: Basis
12.05.04
Section PageDate
© KEB Antriebstechnik, 2002
All Rights reserved
Chapter
Functional DesriptionOperating and Unit Data
Adr.
min max
default
0211h
ru.17 Active current
0,1
A
-
3276,7- 3276,7
Display of the torque-forming active current (stator losses already deducted). Negative current corresponds to generatoric
operation, positive current corresponds to motoric operation. The more precise the input of the motor data , the more
precise the indication of the active current. The maximum values depend on the size of the inverter.
Adr.
min max
default
Adr.
min max
default
0212h
ru.18 Actual DC voltage
1
V
-
10000
Display of actual DC-link voltage in volt. Typical values:
Normal operation: 230V-class 300-330V over volt. (E.OP): approx. 400V under volt. (E.UP): approx. 216V
400V-class 530-620V approx. 800V approx. 240V
0213h
ru.19 Peak DC voltage
1
V
-
10000
ru.19 allows the detection of short-time peak DC voltage during an operating cycle. For that the highest detected value
of ru.18 is stored in ru.19. The peak value memory is cleared by pressing the keys UP, DOWN or ENTER or by bus by
writing any chosen value to the address of ru.19. The disconnection of the inverter also results in a clearing of the
memory.
Adr.
min max
default
0214h
ru.20 Output voltage
1
V
-
7780
Display of actual output voltage.
