KEB COMBIVERT F5-M / S10

Name: Basis

12.05.04

Chapter Section Page Date

Functional Desription Operating and Unit Data

Adr.

min max

default

0216h

ru.22 Internal input state

40950

Display of the currently set external and internal digital inputs. The input is considered as set when it is available as

active signal for further processing (i.e. acceptance by strobe, edge triggering or logic operation). According to the table

(ru.21) a certain decimal value is given out for each digital input. If several inputs are set then the sum of their decimal

values is displayed (see Chapter 6.3 ÑDigital Inputsì).

Adr.

min max

default

0215h

ru.21 Input terminal state

40950

Display of the current set digital inputs. The logic levels on the input terminals or on the internal inputs are indicated

regardless whether the input is inverted or the internal acceptance is effected through edge-triggering or Strobe (also

see Chapt. 6.3 ÑDigital inputsì). According to following table a specific decimal value is given out for each digital input.

If several inputs are controlled, the sum of the decimal values is indicated.

Bit -No. Decimal value Input Terminal

0 1 ST (prog. input Ñcontrol release / resetì) X2A.16

1 2 RST (prog. input Ñresetì) X2A.17

2 4 F (prog. input Ñforwardì) X2A.14

3 8 R (prog. input Ñreverseì) X2A.15

4 16 I1 (prog. input 1) X2A.10

5 32 I2 (prog. input 2) X2A.11

6 64 I3 (prog. input 3) X2A.12

7 128 I4 (prog. input 4) X2A.13

8 256 IA (internal input A) none

9 512 IB (internal input B) none

10 1024 IC (internal input C) none

11 2048 ID (internal input D) none
