KEB COMBIVERT F5-M / S
Name: Basis
12.05.04
Section PageDate
© KEB Antriebstechnik, 2002
All Rights reserved
Chapter
Functional DesriptionOperating and Unit Data
Adr.
min max
default
0217h
ru.23 Output condition state
1
-
-
2550
With parameters do.0Ödo.7 switching conditions can be selected which serve as basis for the setting of the outputs.
This parameter indicates which of the selected switching conditions are met, before they are linked by the programmable
logic or inverted (see Chapter 6.3 ÑDigital Outputs). According to following table a certain decimal value is given out for
the parameters do.0Ödo.7. If several of the switching conditions selected with these parameters are met, then the sum
of the decimal values is displayed.
Bit -No. Decimal value Output
0 1 switching condition 0 (do.0)
1 2 switching condition 1 (do.1)
2 4 switching condition 2 (do.2)
3 8 switching condition 3 (do.3)
4 16 switching condition 4 (do.4)
5 32 switching condition 5 (do.5)
6 64 switching condition 6 (do.6)
7 128 switching condition 7 (do.7)
Adr.
min max
default
0217h
ru.24 State of output flags
1
-
-
2550
Display of the links after logic step 1. The selected switching conditions are linked in logic step 1 (do.8...24) and
indicated here (see Chapt. 6.3 ÑDigital outputsì). According to following table a specific decimal value is given out for
each linkage. If several links are set, the sum of the decimal values is indicated.
Bit -No. Decimal value Output
0 1 flag 0
1 2 flag 1
2 4 flag 2
3 8 flag 3
4 16 flag 4
5 32 flag 5
6 64 flag 6
7 128 flag 7
