KEB COMBIVERT F5 Servo User Manual

6
1
KEB COMBIVERT F5-M / S18
Name: Basis
12.05.04
Chapter Section Page Date
© KEB Antriebstechnik, 2002
All Rights reserved
Functional Desription Operating and Unit Data
This parameter displays the actual angular difference between master and slave.
Adr.
min max
default
023Ah
ru.58 Angular difference
1
Inc
-
This parameter displays the actual factor of the rotor adaption.
Adr.
min max
default
023Bh
ru.59 Rotor adaption factor
1
%
-
1000
2147483647
-2147483648
This parameter displays the actual position index of the position profile.
Adr.
min max
default
023Ch
ru.60 Actual position index
1
-
-
2550
This parameter displays the target position of the actual position index.
Adr.
min max
default
023Dh
ru.61 Target position
1
Inc
-
2147483647
-2147483648
This parameter displays the speed of the actual position index.
Adr.
min max
default
023Fh
ru.63 Profil speed
0,125
rpm
-
4000-4000
This parameter displays the rated dc link voltage automatically detected by the inverter. The value is detected at power-
on.
Adr.
min max
default
0244h
ru.68 Rated DC voltage
1
V
-
10000
This parameter displays the distance to the zero signal after relieving the reference switch.
Adr.
min max
default
0245h
ru.69 Distance reference - zero point
1
Inc
-
-2147483647-2147483648
