KEB COMBIVERT F5-M / S
Name: Basis
12.05.04
Section PageDate
© KEB Antriebstechnik, 2002
All Rights reserved
Chapter
Functional DesriptionOperating and Unit Data
Adr.
min max
default
0247h
ru.71 Teach / scan position
1
Ink
-
2147483647
-2147483648
Adr.
min max
default
0249h
ru.73 relative set torque
0,1
%
-
100,0
-100,0
This parameter displays the adjusted setpoint torque (ru.11) at the input percent-related to the absolute torque setpoint
(cs.19).
Adr.
min max
default
024Ah
ru.74 relative actual torque
0,1
%
-
100,0
-100,0
This parameter displays the current actual torque (ru.12) at the input percent-related to the absolute torque setpoint
(cs.19).
Adr.
min max
default
024Eh
ru.78 relative actual value display
0,1
%
-
100,0
-100,0
This parameter displays the current actual value (ru.7) percent-related to the max. setpont clockwise rotation (oP.10).
To protect servo motors in the field weakening range against countervoltages, an EMF-dependent speed must not be
exceeded. The calculated value is placed in front of all other limits. It is displayed in ru.78.
Adr.
min max
default
024Fh
ru.79 absolute speed value (EMF)
0,125
1/min
-
4000-4000
This parameter displays the current teach position. The position remains until a new position is teached.
