Functional Desription Operating and Unit Data
With do.51 the digital output signals can be assigned to the hardware outputs (see chapter 6.3). This parameter displays
the status of the output signals before the assignment according to following table. If several outputs are set, the total
sum of their decimal values is indicated.
Adr.
min max
default
0250h
ru.80 digital output state
1
-
-
2550
Bit -No. Decimal value Output Terminal
0 1 O1 (Transistor output 1) X2A.18
1 2 O2 (Transistor output 2) X2A.19
2 4 R1 (Relay RLA,RLB,RLC) X2A.24...26
3 8 R2 (Relay FLA,FLB,FLC) X2A.27...29
4 16 OA (Internal output A) keine
5 32 OB (Internal output B) keine
6 64 OC (Internal output C) keine
7 128 OD (Internal output D) keine
ru.81 displays the current active power of the inverter. In regenerative operation the negative values are displayed.
Adr.
min max
default
0251h
ru.81 active power
0,01
kW
0,01
400,00-400,00
