KEB COMBIVERT F6 - Dimensions Air-Cooled Inverter Through-Mount Version; Figure 3: Dimensions Air-Cooled Inverter Through-Mount Version

3.5.2 Dimensions air-cooled inverter through-mount version
12512512512512512577,5
307
325
125
905
77,5
9
887
M8
22x
340
273,5
287,5
176
162
920
Housing P
Weight 96 kg
Dimensions All dimensions in mm
Optional Seal for IP54 can be mounted on top or bottom side (=> Connections to the coolant)
Figure 3: Dimensions air-cooled inverter through-mount version
42
DIMENSIONS AND WEIGHTS
