4.3 Series connection cooling circuit
4.3.1 General instructions
Does the drive converter system work at rated operation the execution of the coolant
circuit can be carried out in a series circuit.
It should be noted that the temperature is analog measured in the slave devices and
an error signal is given digitally to the master.
Thecoolantreturnowshouldalwaysbeattachedatthemasterinordertodisplay
real temperatures.
Thevolumeowtobeselecteddependsonthesizeofthedevice,theoutputcurrent
at rated operation and the resulting power loss for the drive converter system.
Thecorrelationbetweentotalpowerdissipation,volumeowandtemperaturedif-
ference are shown in the diagram Series connection of liquid coolers and must be
within the recommended operational range.
ATTENTION
Themaximumtemperaturedifferencebetweenowandreturnow
must not be exceeded.
Ifthevolumeow(above30l/min)isselectedtoolarge,increases
the risk of erosion in the liquid cooler.
Series connection of liquid-cooled devices with stainless steel
tubes is not permitted, since the total system pressure can increase
above 10 bar.
=> Pressure drop aluminium heat sink with stainless steel tubes.
ThecoolingowmustalwaysbestartedbeforestartingtheKEB
COMBIVERT.
51
MECHANICAL INSTALLATION
