1502756-02 - 144 -
Fig. 74: Wiring diagram for extraction capacity regulation with product
Item
Description
Item
Description
1
Control cabinet, product
2
Control cabinet, extraction
capacity regulation
1.1
Frequency converter
Tab. 60: Wiring diagram for extraction capacity regulation with product
2. Connect the cables according to the wiring diagram.
