Kemper WeldFil Compact - Page 146

EN
1502756-02 - 146 -
Item
Description
Item
Description
1
Cable shielding
4
EMC cable gland
2
EMC cable clamp
5
Connection cable
3
Motor connection panel
Tab. 61: Connecting the motor cable shielding
5. When connecting the motor cable [e] (item 5), make sure that the cable
shielding (item 1) is screwed to the EMC cable gland (item 4) as shown
in the illustration.
