Kemppi MasterMig 353 User Manual

MasterMig 353, 355
Operating manual- EN
2.2 Installing cooling unit (optional)
The MasterMig cooling unit must be installed by authorized service personnel.
Tools needed:
1. Remove the small connector cover in the rear of the power source.
2. Route the cooling unit's connection cables so that they remain accessible through the next steps.
3. Lift the MasterMig device on top of the cooling unit so that the fixing plates align and go into their slots.
Ensure that the cooling unit's connection cables are not caught and/or damaged between the edges.
© Kemppi
13
1921960 / 2217

Kemppi MasterMig 353 Specifications

General

Brand	Kemppi
Model	MasterMig 353
Category	Welding System
Language	English
