MasterMig 353, 355
Operating manual- EN
1.2 MasterMig device
Front
1. Transportation handle (also for mechanical lifting when the device is not installed on a cooling unit or cart)
2. Control panel
3. Work lights ON/OFF
4. Work light
5. Control cable connector
6. Earth return cable connector
7. Welding cable euro connector
8. Front locking interface
>> For locking on top of the cooling unit or on the cart
9. Connector for subfeeder synchronization kit (optional)
10. Wire feed cabinet hatch.
Rear
1. Shielding gas hose connector
2. Mains cable
© Kemppi
7
1921960 / 2217
