MasterMig 353, 355
Operating manual- EN
1.3 MasterMig Cooler cooling unit (optional)
Front
1. Cooler container cap
2. Cooling liquid level indicator
3. Cooling liquid circulation button
>> Keeping the button pressed activates the pump and circulates the cooling liquid throughout the system. Once
released, the pump stops.
4. Front locking interface
>> For locking on the cart
5. Front locking interface
>> For locking to the power source
6. Coolant inlet connector (red)
7. Coolant outlet connector (blue).
Rear
1. Rear locking interface
>> For locking to the power source
2. Rear locking interface
>> For locking on the cart.
