MasterMig 353, 355
Operating manual- EN
5.3 Wire feeder consumables
This section lists the feed rolls and wire guide tubes available both separately and in consumable kits. The consumable
kits contain recommended feed roll and wire guide tube combinations for selected filler wire materials and diameters.
The wire feeder consumables can be ordered in Configurator.kemppi.com.
In the tables, standard refers to plastic feed rolls and heavy-duty refers to metal feed rolls. The materials mentioned first
refer to primary suitability and the materials mentioned inside brackets refer to secondary suitability.
Wire feeder consumable kits
The table below lists the recommended consumable kits for selected filler wire materials and diameters.
Wire feeder consumable kits
Filler wire material Feed roll profile*
Filler wire diameter
(mm)
Consumable kit code,
standard
Consumable kit code,
heavy-duty
Fe (MC/FC)
V-groove 0.8−0.9 F000488 F000492
1.0 F000489 F000493
1.2 F000490 F000494
Ss (Fe, Cu)
V-groove 0.8−0.9 F000455 -
1.0 F000456 -
1.2 F000457 -
Ss (Fe)
V-groove 0.8−0.9 - F000458
1.0 - F000459
1.2 - F000460
MC/FC
V-groove, knurled 1.0 F000499 F000502
1.2 F000500 F000503
Al
U-groove 1.0 F000461 -
1.2 F000462 -
Wire guide tubes
The table below lists the wire guide tubes available.
Wire guide tubes
Filler wire material
Filler wire diameter
(mm)
Inlet guide tube Middle guide tube Outlet guide tube
Al, Ss (Fe, MC/FC)
0.6 SP007293 SP007273 SP016608
0.8−0.9 SP007294 SP007274 SP011440
1.0 SP007295 SP007275 SP011441
1.2 SP007296 SP007276 SP011442
Fe, MC/FC
0.6 (SP007293) (SP007273) SP016613
0.8−0.9 SP007536 (SP007274) SP016614
1.0 SP007537 (SP007275) SP016615
1.2 SP007538 (SP007276) SP016616
© Kemppi
70
1921960 / 2217
