X8 MIG WELDER 2.3 Installation
1.
Open the top cover latch.
2.
Lift the top cover up.
3.
Cut and file the tip of the filler wire.
Note:
The sharp cut tip of the filler wire may cause damage to the wire liner, if not filed.
4.
Press Wire retract to pull back the remaining filler wire from the welding gun.
5.
Push the wire spool locking cover aside.
6.
Lift the wire spool from the wire feeder.
7.
Loosen and pull the wire spool brake halves apart.
Install a new wire spool:
OPERATING MANUAL | EN 44
©
KEMPPI | 2018-09-28
