Kemppi X8 MIG User Manual

X8 MIG WELDER 2.3 Installation
2.3.3.4 Replacing wire guides
The wire feed mechanism includes two wire guide tubes. Replace them when the filler wire diameter grows
or the material changes.
2
1
1. Inlet tube
Pull out the inlet tube and insert a new one. There is no additional locking.
2. Middle tube
A metal piece locks the middle wire guide tube in its place. Turn the piece aside to free the middle wire
guide tube for replacement. Turn it back to lock down the new middle wire guide tube.
2.3.3.5 Changing wire spool
Note:
Install the welding gun to the wire feeder before installing the wire spool.
Caution:
If you change the filler wire to a different diameter or material, change the feed rolls accordingly.
Proceed as follows:
Remove the wire spool:
OPERATING MANUAL | EN 43
©
KEMPPI | 2018-09-28
