X8 MIG WELDER 2.3 Installation
Changing contact tip (gas-cooled gun)
1.
Remove the contact tip.
2.
Replace the contact tip adapter / gas diffuser, if needed. Screw in and hand-tighten the new adapter as
tight as possible (no tool is needed). Make sure there is no gap between the contact tip adapter and the
black plastic bushing.
Note:
It is important to tighten the adapter properly to enable a tight connection of the contact tip to
the gun.
OPERATING MANUAL | EN 68
©
KEMPPI | 2018-09-28
