6 Remote Operations
74 Keysight 11713D/E Operating and Service Manual
Examples
To set the pulse drive width:
CONF:BANK2:PULS:WIDT 20
To query the set pulse drive width:
CONFigure[:BANK1]:PULSe:WIDTh?
CONFigure:BANK2:PULSe:WIDTh?
Related Commands
:CONFigure[:BANK1]:X/:CONFigure[:BANK1]:Y
:CONFigure:BANK2:X/:CONFigure:BANK2:Y
CONFigure[:BANK1]/CONFigure:BANK2
CONFigure[:BANK1]:TTL/CONFigure:BANK2:TTL
CONFigure[:BANK1]:PULSe:DRIVe
CONFigure:BANK2:PULSe:DRIVe
ATTenuator[:BANK1]:X/ATTenuator[:BANK1]:Y
ATTenuator:BANK2:X/ATTenuator:BANK2:Y
ATTenuator[:BANK1]:X/ATTenuator[:BANK1]:Y
ATTenuator:BANK2:X/ATTenuator:BANK2:Y
Sets the attenuation level of corresponding attenuator(s).
ATTenuator[:BANK1]:X <NR1>
ATTenuator:BANK2:X <NR1>
Examples
To set the attenuation level to 4:
ATT:X 4
To query the set attenuation level:
ATTenuator[:BANK1]:X?
ATTenuator:BANK2:X?
NOTE
CONFigure[:BANK1]:PULSe:DRIVe, CONFigure:BANK2:PULSe:DRIVe,
CONFigure[:BANK1]:PULSe:WIDTh and CONFigure:BANK2:PULSe:WIDTh SCPI
commands are only supported for 11713D and 11713E instruments.
Query? Yes
Set? Yes
Set/.Return Parameters Attenuation level of corresponding attenuator
Minimum n/a
Maximum n/a
Units n/a
