[SOURce:]VOLTage:PROGramming:SOURce INTernal|EXTAC|EXTDC
[SOURce:]VOLTage:PROGramming:SOURce?
Sets the voltage programming source.
Parameter Typical Return
INTernal|EXTAC|EXTDC INT, EXTAC, or EXTDC
Set the voltage programming source to external AC:
VOLT:PROG:SOUR EXTAC
The EXTAC and EXTDC modes require the analog interface card.
The *RST command sets this parameter to INTernal.
[SOURce:]VOLTage:RANGe[:UPPer] 155|310|MINimum|MAXimum
[SOURce:]VOLTage:RANGe[:UPPer]? [MINimum|MAXimum]
Sets the voltage range. If the voltage range is switched, the VOLT:TRIG and VOLT:OFFS:TRIG settings
are cleared, and ABORt[:ALL] is applied.
Parameter Typical Return
155|310|MINimum|MAXimum +2.70000E+02
Set the voltage range to 310 V
VOLT:RANG MAX
You may only set this parameter if output is OFF.
Setting this parameter turns voltage autoranging OFF and aborts both TRANsient and ACQuire
operations.
The *RST command sets this parameter to 155.
If you enter a value between 0 and 155, the 155 V range will be chosen. If you enter a value above 155
V, the 310 V range will be chosen.
[SOURce:]VOLTage:RANGe:AUTO ON|1|OFF|0
[SOURce:]VOLTage:RANGe:AUTO?
Enables or disables voltage autoranging. If this parameter changes, the VOLT:TRIG and
VOLT:OFFS:TRIG settings are cleared, and all operations are aborted.
Parameter Typical Return
ON|1|OFF|0 0(OFF)or1(ON)
Turn on voltage autoranging:
VOLT:RANG:AUTO 1
The *RST command sets this parameter to OFF.
