Field Display Description
Status Off Output is disabled
CV Constant voltage mode
CLrms Current limit mode
PL Power limit mode
OV Overvoltage protection; output OFF
OC Overcurrent protection (rms/avg); output OFF
OCPK Overcurrent protection (peak); output OFF
OP Overpower protection; output OFF
OT Overtemperature protection; output OFF
LV Low voltage protection (AC input); output OFF
WDG Watchdog timeout error; output OFF
SF Sense fault protection; output OFF
Range LOW Selected range up to 155 VAC (219 VDC)
HIGH Selected range up to 310 VAC (438 VDC)
AUTO Autoranging selected (not available in EXT-AC or EXT-DCmode)
Interface Err One or more messages in error queue
LAN (displayed) LXI LAN "No fault"
LAN (blinking) LXI LAN "Identify"
(LAN section blank) LXI LAN "Fault"
IO Remote activity via the LAN connection
If AUTO is selected prior to entering either of the external programming modes, the range selected by
autoranging is retained until changed by the user. The range field is updated to reflect the actual
range when the external programming mode is first entered (if AUTO is selected).
2User Information
70 Keysight AC6800B Series Operating and Service Guide
