Keysight Technologies B1500A Configuration And Connection Guide

Keysight B1500A Configuration and Connection Guide
4-9
Connection and Ordering Examples
Four terminal device
Table 4-11 Key specification
Table 4-12 Configuration Example
Item Range Note
Maximum I/V range 100 mA / 100 V
Minimum I/V resolution 10 fA / 0.5 μV
Model option Description Qty
B1500A Semiconductor Device Analyzer Mainframe 1
B1500A-015/030 1.5 m or 3 m length of bundled cables 1
B1500A-A01 Standard package, contains four MPSMU and eight triaxial cables 1
B1500A-A5F Test fixture for packaged device measurement, adds one 16442B (Optional) 1
