Keysight B1500A Configuration and Connection Guide
Connection and Ordering Examples
Configuration example of WGFMU
4.3 Configuration example of WGFMU
This chapter describes prober or Fixture connection and ordering example of Keysight
B1500A Semiconductor Device Analyzer for NBTI characterization by WGFMU.
4.3.1 Ultra-fast 1 us NBTI characterization using the B1530A
WGFMU module
Figure 4-13 Configuration for ultra-fast NBTI characterization
Table 4-37 Target device and application
Table 4-38 Key specification
Device Application Note
FET NBTI, PBTI
Item Range Note
I
d
fast sampling 1 μs
I
d
-V
g
fast sweep 1 μs per point
MPSMU
Triaxial cable
Semse
Force
B1500A
MPSMU
Sense
Force
Interlock cable
WGFMU
Channel 2
Channel 1
SMU 2
WGFMU 2
Output 2
WGFMU cable
SMU 1
WGFMU 1
Output 1
Triaxial cable
WGFMU cable
Connector plate
Fixture/Prober
DUT
Interlock
G
D
Subs
S
RSU
RSU
WGFMU Connector Adapter
(16493R-801)
SMA
SMA
