Keysight B1500A Configuration and Connection Guide
Connection and Ordering Examples
Four terminal device
4.2.2 General IV/CV characterization
Figure 4-5 General IV/CV configuration
Table 4-13 Target device and application
Device Application Note
FET I
d
-V
d
, V
th
, BV
dss
, I
d
leak, I
g
leak, C
gb
Connector plate
Fixture/Prober
DUT
Interlock
GSWU (N1302A-200)
GSWU cable (N1302A-201/202)
G
D
Subs
S
MPSMU
SCUU cable
(N1301A-102)
Sense
Force
B1500A
MPSMU
Sense
Force
Interlock cable
MFCMU
Hpot
Hcur
Lpot
Lcur
12
Triaxial cable
SCUU
(N1301A-100)
CMUH
Force1/
CMUL
Force2/
Sense1
Sense2
GSWU
MPSMU
Sense
Force
MPSMU
Sense
Force
Triaxial cable
