Keysight B1500A Configuration and Connection Guide
4-11
Connection and Ordering Examples
Four terminal device
Table 4-14 Key specification
Table 4-15 Configuration Example
Item Range Note
Maximum I/V range 100 mA / 100 V
Minimum I/V resolution 10 fA / 0.5 μV
CV frequency range 1 kHz to 5 MHz
Maximum DC bias to CV 100 V MPSMU and SCUU is required.
Model option Description Qty
B1500A Semiconductor Device Analyzer Mainframe 1
B1500A-015/030 1.5 m or 3 m length of bundled cables 1
B1500A-A01 Standard package, contains four MPSMU and eight triaxial cables 1
B1500A-A20 Capacitance measurement add-on package, adds the MFCMU and one CMU
cable
1
N1301A Accessories for CMU 1
N1301A-100 SMU CMU unify unit (SCUU) 1
N1301A-102 SCUU cable, 3 m 1
N1301A-110 SCUU magnetic stand (Optional) 1
N1301A-200 Guard switch unit (GSWU) 1
N1301A-201/202 GSWU cable, 1.5 m or 3 m 1
B1500A-A5F Test fixture for packaged device measurement, adds one 16442B (Optional) 1
