Keysight Technologies B1500A Configuration And Connection Guide

4-20
Keysight B1500A Configuration and Connection Guide
Connection and Ordering Examples
Four terminal device
4.2.7 50 μs Pulse IV characterization (Two MCSMU)
Figure 4-10 50 μs pulse MCSMU configuration by two MCSMU modules
MPSMU
Triaxial cable
Sense
Force
B1500A
Interlock cable
MCSMU
Sense (H/L)
Force (H/L)
MCSMU
Sense (H/L)
Force (H/L)
GNDU
Froce/Sense
Sense
Force Force
N1255A
Connection Box
Sense
Force
Force
Force
Force
N1254A-100
GNDU Adapter
GNDU cable
Control cable
Triaxial cable
Sense
Sense
Triaxial cable
GNDU/SMU
Triaxial cable
MCSMU2
MCSMU1
Sense
Sense
High1
High2
Force
Sense
Low
Connector plate
Fixture/Prober
DUT
Interlock
Coverage of Configuration Example
G
D
Subs
S
