Keysight B1500A Configuration and Connection Guide
4-21
Connection and Ordering Examples
Four terminal device
Table 4-28 Target device and application
Table 4-29 Key specification
Table 4-30 Configuration Example
Device Application Note
FET I
d
-V
d
, V
th
, BV
dss
, I
d
leak, I
g
leak
Item Range Note
Maximum I/V range 1 A / 30 V Drain/Gate terminal by MCSMU
Maximum I/V range 100 mA / 100 V Substrate terminal by MPSMU
Minimum I/V resolution 10 pA / 0.2 μV Drain/Gate terminal by MCSMU
Minimum I/V resolution 10 fA / 0.5 μV Substrate terminal by MPSMU
Minimum pulse width 50 μs Drain/Gate terminal by MCSMU
I
d
fast sampling 2 μs Drain/Gate terminal by MCSMU
Model option Description Qty
B1500A Semiconductor Device Analyzer Mainframe 1
B1500A-015/030 1.5 m or 3 m length of bundled cables 1
B1500A-A00 Empty package for custom solution, contains no measurement module 1
B1500A-A11 MPSMU add-on package, adds one MPSMU and two triaxial cables 1
B1500A-A1B MCSMU add-on package, adds two MCSMU, connection box and four
triaxial cables
1
B1500A-A5F Test fixture for packaged device measurement, adds one 16442B (Optional) 1
16494A Triaxial cable 6
To Next Page
