1-26

Keysight B1500A Configuration and Connection Guide

B1500A Product Configuration

Upgrade products for the B1500A series

1.4.3 Module type and locations

Module locations when the B1500A is shipped from the factory are shown in Table 1-25.

This table shows the relative locations by the module types.

If the SPGUs are installed, the SPGUs must be installed in the slots from the slot number 1.

And if the SPGU and the WGFMU are not installed and the HPSMUs are installed, the

HPSMUs must be installed in the slots from the slot number 1. Then the same type of

modules must be installed in the contiguous slots.

For example, if the module configuration is two HPSMU, two MPSMU, and one CMU, the

B1500A will be shipped with the HPSMUs of the slots 1 to 4, the MPSMUs of the slots 5

to 6, the CMU of the slot 7, and the blank panels of the slots 8 to 10.

Table 1-25 Module Installation Rule in the Factory

NOTE About SMU number

The SMU number is counted up from bottom to top. Use the SMU number label furnished

with the B1500A or equivalent to identify the SMU number.

NOTE About HVSPGU and WGFMU modules

The HVSPGU and the WGFMU cannot be installed to slot 10. The SPGU module must be

installed in the slots from the slot number 1.

Slot Number and Location SMU type and port number

10 top B1514A Medium Current SMU (MCSMU)

B1520A Multi Frequency CMU (MFCMU)

B1511A Medium Power SMU (MPSMU)

B1511B Medium Power SMU (MPSMU)

B1517A High Resolution SMU (HRSMU)

B1510A High Power SMU (HPSMU)

B1530A WGFMU

1 B1525A High Voltage SPGU (HVSPGU)

0 bottom GNDU/ADC (Always installed)
