Keysight B1500A Configuration and Connection Guide
B1500A Product Configuration
Options of B1500A series
1.2 Options of B1500A series
This section describes Option items of the Keysight B1500A Semiconductor Device
Analyzer.
Table 1-3 B1500A Options
Model/
Option
Description OP Instruction
Mainframe
B1500A Semiconductor device analyzer
mainframe
• Select option 015 or 030 to specify cable length.
• Select option 050 or 060 to specify Power li
ne
frequency.
• The following accessories are included. See
T
able 1-3, for more details of furn
ished
accessories.
Keyboard
USB mouse
Stylus pen
One Interlock cable (1.5 m or 3.0 m)
One
GNDU cable (1.5 m or 3.0 m)
One Triaxial cable (1.5 m or 3.0 m)
GNDU to Kelvin adaptor
Select standard packages (mandatory)
B1500A-A00 Empty package for custom solution • No module is included in B1500A mainframe
• Specify Add-on package option.
B1500A-A01 Standard pack 1 -Standard package
(Mid PWR unit 4ea, cables)
• Standard package-1 contains four MPSMU an
d
eight Triaxial cables.
• Cable length 1.5 m or 3.0 m is specified by
option 015 or 030.
B1500A-A02 Standard pack 2 -High resolution
package (High resolution unit 4ea,
cables)
• Standard package-2 contains four HRSMU and
eight triaxial
cables.
• Cable length 1.5 m
or 3.0 m is specified by
option 015 or 030.
B1500A-A03 Standard pack 3 -High power package
(High PWR unit 2ea, Mid PWR unit
2ea, cables)
• Standard package-3 contains two HPSMU, two
MPSMU, and eight triaxial cables.
• Cable length 1.5 m or 3.0 m is specified by
opti
on 015 or 030.
B1500A-A04 Standard pack 4 - Flash pack (Mid
PWR unit 2ea, Hi-res unit 2ea, PGU,
accessories)
• Standard package-4 contains two MPSMU, two
HRSMU, one HVSPGU and accessories for
flash memory cell measurement See Table 1-8.
