Keysight B1500A Configuration and Connection Guide
1-7
B1500A Product Configuration
Options of B1500A series
Select add-on packages (optional)
B1500A-A10 Add-on package - High power source
monitor unit (B1510A) 1ea, cables
• HPSMU add-on package adds one HPSMU and
two triaxial cables.
• Cable length 1.5 m
or 3.0 m is specified by
option 015 or 030.
B1500A-A11 Add-on package - Mid power source
monitor unit (B1511B) 1ea, cables
• MPSMU add-on package adds one MPSMU and
two triaxial cables.
• Cable length 1.5 m or 3.0 m is specified by
option 015 or 030.
B1500A-A17 Add-on Package - High resolution
source monitor unit (B1517A) 1ea,
cables
• HRSMU add-on package adds one HRSMU and
two triaxi
al cables.
• Cable length 1.5 m or 3.0 m is specified by
option 015 or 030.
B1500A-A1A Add-on Package - B1514A Medium
current source/monitor unit 1ea w/
connection box
•50 μs pulse MCSMU add-on package adds one
MCSMU, two triaxial cables and the N1255A
connection box.
• Cable length 1.5 m
or 3.0 m is specified by
option 015 or 030.
B1500A-A1B Add-on Package - B1514A Medium
current source/monitor unit 2ea w/
connection box
•50 μs pulse MCSMU two modules add-on
package adds two MCSMU, four triaxial cables
and the N1255A connection box.
• Cable length 1.5 m or 3.0 m is specified by
opti
on 015 or 030.
B1500A-A20 Add-on package - Capacitance
measurement unit (B1520A) 1ea, cable
1ea
• Capacitance measurement add-on package
adds
the MFCMU and one CMU cable.
• Cable length 1.5 m or 3.0 m is specified by
option 015 or 030.
B1500A-A25 Add-on package - Pulse generator unit
(B1525A) 1ea, cables
• HVSPGU add-on package adds one HVSPGU
and two SPGU cables.
• Cable length 1.5 m
or 3.0 m is specified by
option 015 or 030.
B1500A-A28 Add-on package - Atto sense switch
unit (E5288A) 1ea, cables for High
Resolution Source Monitor Unit
• ASU add-on package for HRSMU adds one
ASU, one D-sub cable, and one triaxial cable.
• Cable length 1.5 m or 3.0 m is specified by
option 015 or 030.
B1500A-A29 Add-on package - Atto sense switch
unit (E5288A) 1ea, cables for Mid
Power Source Monitor Unit (B1511B)
• ASU add-on package for B1511B MPSMU adds
one ASU, one D-sub cable,
and one triaxial
cable.
• Cable length 1.5 m or 3.0 m is specified by
option 015 or 030.
• ASU and D-sub cable require ASU connector on
the B151
1B MPSMU module.
Model/
Option
Description OP Instruction
