4-14
Keysight B1500A Configuration and Connection Guide
Connection and Ordering Examples
Four terminal device
4.2.4 High resolution IV characterization (ASU)
Figure 4-7 Precision IV configuration
Table 4-19 Target device and application
Table 4-20 Key specification
Device Application Note
FET I
d
-V
d
, V
th
, BV
dss
, I
d
leak, I
g
leak
Item Range Note
Maximum I/V range 100 mA / 100 V
Minimum I/V resolution 0.1 fA / 0.5 μV
HRSMU
Triaxial cable
D-sub
Force
B1500A
HRSMU
Sense
Force
Interlock cable
HRSMU
Sense
Force
HRSMU
Sense
Force
D-sub
Force Force
Sense
Triaxial/D-sub cable for ASU
Connector plate
Fixture/Prober
DUT
Interlock
G
D
Subs
S
ASU
To Next Page
