Keysight B1500A Configuration and Connection Guide
4-15
Connection and Ordering Examples
Four terminal device
Table 4-21 Configuration Example
NOTE The low current level is around 1 nA with the 16442B test fixture.
NOTE To connect ASU, MPSMU (B1511B) option A11 is also available.
Model option Description Qty
B1500A Semiconductor Device Analyzer Mainframe 1
B1500A-015/030 1.5 m or 3 m length of bundled cables 1
B1500A-A02 High resolution package, contains four HRSMU and eight triaxial cables 1
B1500A-A28 ASU add-on package, adds one ASU, one D-sub cable, and one triaxial cable 1
B1500A-A5F Test fixture for packaged device measurement, adds one 16442B (Optional) 1
