1-28
Keysight B1500A Configuration and Connection Guide
B1500A Product Configuration
EasyEXPERT group+ software
1.5 EasyEXPERT group+ software
This section describes Keysight EasyEXPERT group+ software and related options. For
technical details of EasyEXPERT group+ software or EasyEXPERT group+ software for
PC, refer to data sheet of B1500A or www.keysight.com/find/easyexpert
web site.
1.5.1 Functions and capabilities
Keysight EasyEXPERT group+ software is a specially-designed Windows application
program for controlling Keysight B1500A. The EasyEXPERT group+ provides the easy
and effective measurement and analysis environment with intuitive graphical user interface
(GUI), touch screen LCD panel, keyboard, and mouse. Some of the functions are listed
below.
• Single measurement, repeat measurement, and append measurement
• Switching matrix control
• Measurement/setup data management by workspace
• Graph display and analysis with markers, cursors, and lines; and auto analysis
• Password protection and user level access control to protect the data an
d measurement
setup
•
Data import/export capability, data output by CSV/XML format, and graph output by
EMF/BMP/GIF/PNG format
• Maintenance; self-test and self-calibration
NOTE The EasyEXPERT group+ is upgradeable from the previous generation of
EasyEXPERT/Desktop EasyEXPERT software.
NOTE The latest revision of the EasyEXPERT update package can be obtained from Keysight
Technologies web site.
Operation mode
The EasyEXPERT group+ has the following measurement operation environments.
• Application test mode - The EasyEXPERT group+ contains an application library that
supports typical measurements for CMOS devices, TFT, BJT, memory, nanotechnolo
gy
devices
such as CNT FET, and so on. The application library includes more
than three
hun
dred test definitions. This mode realizes application oriented point-and-click test
setup and execution.
• Classic test mode - You can perform measurements by
using the user interface similar
to th
e semiconductor parameter analyzers such as Keysight 4155/4156 series. Th
e
setup can
be made by entering values into the setup tables used for the meas
urement
mo
dule control. And it can be saved and recalled as your setup (My Favorite Setup).
• Tracer test mode - Curve tracer test mode. This test allows you to
perform the high
speed I-V measurement on one screen. The
Tracer test screen provides
GUI for
selecting the used channels, setting the
sweep output, and displayi
ng the measurement
